Maynuo M9711 Programmable Dc Electronic Load 0-30a/0-150v/150w

US $545.00

shenzhen, China
Jan 29th

Open on mobile:
QR code

Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CW Over current, over voltage, over power, over heat, polarity reversed protection High-luminance VFD screen with two lines& four channels display Intellegent fan system fan will be automatically initiated according to the temperature Soft start time setting, carrying the power supplier according to the voltage value set Battery testing and short-circuit function Available of dynamic testing and rising edge and falling edge setting Supporting external trigger input and output External current waveform monitor terminal Supporting remote voltage compensation and multidata storage Power-on-self-test, software calibration and standard rack mount Communication mode: RS232/RS485/USB. Application: Production line(cell phone charger, cell phone battery, electric vehicle battery, switching power supplier, linear power supplier), research insititutes, automotive electronics, aeronautics and astronautics,ships, solar cells fule cell, etc. Specification: Model M9711 Input Rating Power 150W Current 0-30A Voltage 0-150V CC Mode Range 0-3A 0-30A Resolution 0.1mA 1mA Accuracy 0.03%+0.05%FS 0.03%+0.05%FS CV Mode Range 0.1-19.999V 0.1-150V Resolution 1mV 10mV Accuracy 0.03%+0.02%FS 0.03%+0.02%FS CR Mode (Voltage and current input value >=10% full measurement) Range 0.03-10K Oh 0.03-5K Oh Resolution 16 bit 16 bit Accuracy 0.1%+0.1%FS 0.1%+0.1%FS CW Mode (Voltage and current input value >=10% full measurement) Range 0-150W 0-150W Resolution 1mW 10mW Accuracy 0.1%+0.1%FS 0.1%+0.1%FS Voltage Measurement Voltage 0-19.999V 0-150V Resolution 1mV 10mV Accuracy 0.015%+0.03%FS 0.015%+0.03%FS Current Measurement Current 0-3A 0-30A Resolution 0.01mA 0.1mA Accuracy 0.03%+0.05%FS 0.03%+0.08%FS Power Measurement(Voltage and current input value >=10% full measurement) Power 100W 150W Resolution 1mW 10mW Accuracy 0.1%+0.1%FS 0.1%+0.1%FS Battery Test Battery Input: 0.1-150V; Max. Mesurement:Capacity=999AH; Resolution=0.1mA; Test Range=1S-16H Dynamic Test Transition List:0-25kHZ; 2.5A/uS; T1&T2:60uS-999S; Accuracy:+15% offset+10%FS Current soft-startup Time 1mS;2mS;5mS;10mS;20mS;50mS;100mS;200mS;500mS;1000mS Accuracy:+15% offset+10%FS Short Circuit Current(CC) =3.3A =33A Voltage(CV) 0V Resistance(CR) =55mOh Temperature Operating 0~40oC Nonoperating -10oC~70oC Dimension W*H*D(mm) 214*108*365 Weight Kg 3.5 We accept Payal only. Items will be shipped via EMS or DHL (approximately 5-7 business days for delivery). If items do not arrive in 10 days, pls feel free to contact us. We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address which you want us to ship. Import duties and taxes are not included in the item price or shipping charges. These charges are the buyer's responsibility. Country Delivery Time Indonesia | Singapore | Malaysia | Thailand | Australia | New Zealand | Papua New Guinea | Malta 3-5 working days Austria | Belgium | Denmark| Finland | France | Germany | Greece | Ireland | Italy | Luxembourg | Norway | Portugal | Spain | Sweden | Switzerland | U.K | Russia | Ukraine | Canada 5-7 working days U.S.A 5-7 working days Africa |South America|Other Countries 5-7 workingdays Exchanges are offered for items that are defective when received, although this is highly unlikely. Please contact us before taking any action. Defective items or problems with your order must be reported within 7 days after receiving. After 7 days, exchanges will not be given, buyer is responsible for Return Shipping Cost. We provide a refund within 7 days(postage will not be refund)and 1 year warranty directly from the manufacturer.Buyer will be responsible for the return shipping cost. IMPORTANT: Please keep all packaging, documentation, packing list, etc. that came with your order. These will be used to verify claims if there are any problem with your order. We can`t help you if you can`t help us verify your claim, if thrown away, we`re not responsible for any claims made. Your feedback is very important for us to improve our service, if you are satisfied with items and service, please leave us a positive feedback with 5 stars rate. Please do not leave negative feedback to me, if you are not satisfied with the item, please feel free to contact us. We will response try our best to resolve the problems for you. Email: equipmentsfinder@hotmail.com Your partner for managing your online business
