Mazak Nexus Turning Center Live Tools 4.4" Thru Hole 15" Hyd Chuck 40 Hp Tools

US $3200

Dover, Kentucky, United States
Jun 22nd

Open on mobile:
QR code

WE ALWAYS CONSIDER ALL REASONABLE OFFERS AND MANY ARE PROMPTLY ACCEPTED AS WE ARE A SMALL DEALER WITH A VERY LOW OVERHEAD. WE URGE YOU TO "CLICK" ON SELLERS OTHER ITEMS AS WE ALWAYS HAVE 40 - 50 OFFERINGS EACH MONTH. You are invited to purchase or "MAKE YOUR BEST OFFER" ON A MAZAK NEXUS QTN-350M/1200, CNC TURNING CENTER WITH "LIVE TOOLS", 15" HYD CHUCK, OD & ID TOOLS, 4.4" SPINDLE BORE, RIGID TAP, FULL CONTOURING "C" AXIS and more with the following approximate specifications and additional equipment: SPECIFICATIONS: Max Swing Over Slant Bed................................................. 29.5" Max Swing Over Cross Slide............................................. 16.5" Max Distance Between Centers....................................... 48" Maximum Cutting Diameter............................................... 16.5" Maximum Turning Length.................................................. 48" Chuck Size............................................................................ 15" Cross Travel (X-Axis).......................................................... 10.13" Longitudinal Travel (Z-Axis).............................................. 48.75" Rapid Traverse Rate .......................................................... 948 IPM Number of Turrets....................,,,,,,,,,,,,,,,,,,,,,..................... 1 Turret Positions.............................................................,..... 12 Spindle Nose...........................,,,,,,,,,,,,,,,,,,,,,,,,,,................... A2-11 Spindle Bore..........................................,,,,,,,,,,,,,,,,,,,,,,,,,,.... 4.4" Bar Capacity......................................,,,,,,,,,,,,,,,,,,,,,,,,,,........ 4" Spindle Speed ..................................,,,,,,,,,,,,,,,,,,,,,,,.......... 30-3300 RPM Spindle Drive Motor............................,,,,,,,,,,,,,,,,,,,........... 40 HP Milling Spind Speed......................,,,,,,,,,,,,,,,,,,,,................ 100-4000 RPM Milling Spindle Motor................................,,,,,,,,,,,,,,,,,,,..... 10 HP Electrics............................................,,,,,,,,,,,,,,,,,,,,,,,,,,,,,..... 480/3/60 Approximate Machine Dimension...........,,,,.................. 88" x 162" Approximate Machine Height...................,,,,,,,,,............. 98" Approximate Machine Weight.................,,,,,,,,.............. 17,500 LBS EQUIPPED WITH: Mazak 640T Nexus CNC Control, RS-232 Port, Multiple Part Program Storage, Live Tooling, Full Contouring C-Axis, 4.4" Spindle Bore Programmable Tailstock with 48" Centers, 15" 3-Jaw Power Chuck, Tool Eye, 12 Position ID/OD Tool Turret, Synchronous Rigid Tap on Milling Spindle Chip Conveyor and Coolant System. All available manuals Includes ID and OD Turning Holder No Live Holders included. CONDITION: Appears to be in Excellent Condition ! Mfg Date: 2005 LOCATION: MID-WESTERN, USA UNDER POWER FOR INSPECTION WILL LOAD AT NO COST This MAZAK NEXUS QTN-350M/1200 appears to be in a "VERY GOOD Used Condition" and you can call Bob Musson at 937 371 1437 or email me at musselcamp@maysvilleky.net with any questions or appointment to inspect the machine under power. Please review our "Feedback and About Us" where you will find that we ALWAYS try to fairly describe all items and offer a 7 day return guarantee (freight prepaid) if item is not as listed. For items shipped by truck contact any or all of the following for reasonable quotations: Chaun at Next Level Logistics 1-612-237-6843 (Excellent Service) ANY LISTED ITEMS DO NOT INCLUDE RIGGING NOR ANY SHIPPING UNLESS NOTED! We additionally have local riggers that can give reasonable quotations as well as quoting containerizing items for overseas shipments. Most items we list are offered locally and could be sold previous to end of store listing. We gladly accept Pay Pal in payment for items $150.00 or UNDER ONLY. For more expensive ITEMS acomodations can be made WITH PRIOR PERMISSION to pay with Pay Pal. We additionally accept personal, company, certified, cashiers checks drawn on recognizable U. S. Banks and accept bank wire transfers. Once payment is received and clears (approx 5 working days for out of state checks, ect.due to Homeland Security Regulations) the item purchased will be shipped or ready for pick up. We thank you in advance for your interest in this item and should you have any questions please feel free to ask them of us and we will try to answer them. WE INVITE YOU TO SEND US INFORMATION CONCERNING ANY USED EQUIPMENT YOU WISH TO LIQUIDATE AS WE WILL TRY TO SECURE A FAIR MARKET VALUE FOR THE ITEMS AND EXPECT VERY LOW COMMISSIONS FOR OUR SERVICES. CONTACT US AT "musselcamp@maysvilleky.net" (kev)
