Mdb-rs232 Usb Pc Interface Bill Acceptor,coin Validator, Card Reader,vending

US $89.99

Fort Worth, Texas, United States
Jan 31st

Open on mobile:
QR code

FYI..Payment must be pay in full, before shipping are process. Shipment may take up to 10-14 days. Depending on your payment received; If you have additional question feel free to contact me via E-mail on Ebay or eddie@lifeintegratedtechnologies.com DESCRIPTION: This Interface Unit (IU) is designed to convert the MDB Bill Acceptor (BA) and MDB Coin Changer (CC) protocol to RS-232 serial protocol. The IU functions as a slave to a master control system. The master may be any control system that supports RS-232 serial communication, for example a PC. OPERATION: The master and slave communication is based on master requests and slave replies. The master sends a status request (or command) to the IU and IU answers by sending its current status. The IU’s typical response to the Master’s request (polling) consists of a header and data bytes. If there is no BA or CC activity, the status is one byte, the header only. When the IU receives data from the BA or CC, it sends a header followed by data bytes in the response to master’s status request. The master must always poll (query) the IU. If the IU does not receive a query from the master in the predefined time slot or IU does not recognize master messages 10 times in row, it will inhibit the BA and CC acceptance. At power up, acceptance of the BA and CC is inhibited. SPECIFICATION: Communication format: Baud rate Start bit Data bits Parity Stop bit 9600 BPS 1 8 NO 1 Timing Specification: Inter-byte (max) Response (max) Master polling times every Time IU waits for the Master’s poll before inhibiting acceptance of the BA and CC (max) 1 ms 50 ms 150 – 300 ms 3 second Hardware Specification. Power Cable Dimensions Weight Min 20 VDC Nominal 24...34 VDC (or 24...30VAC) Max 39 VDC Consumes an idle current < 0.05A 0.5A for 1 sec. when accepting bills Standard computer serial cable Standard MDB cable approx. 100 x 50 x 30 mm approx. 115 g

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Make	FUGENG
MPN	MDB-PC
Model	MDB-PC
Country/Region of Manufacture	China
