Me-8111 Plunger Momentary Limit Switch 1nc+1no For Cnc Mill 3d Printer Door 1pcs

US $9.99

HK, China
Sep 3rd

Open on mobile:
QR code

Product description Product Name: Limit Switch Model: ME-8111 Actuator Type: Plunger Type Rated Voltage: 5A 250V AC / 0.4A 115V DC Contact Configuration: 1NC+1NO Body Size: 64 x 28 x 25mm (L*W*T) Mounting Hole Size: M5 Mounting Hole Distance: 56 x 21mm / 2.2" x 0.83" (L*W) The plunger operated by hydraulic pressure or air cylinder power detects positions highly accurately. The plunger must be installed according to the movement of the dog so that an incorrect load will not be imposed on the plunger. Operating Characteristics: OF max.: 1100g (10.78N) RF min.: 250g (2.45N) PT max.: 2mm OT min.: 0.6mm MD max.: 1mm OP: 26+/-0.8mm Description: Double circuit limit switch with build-in double reed mechanism. Zine alloy and intensive plastic shell, strong and hightly rigid construction. Smooth operation with highter OT. Brass contacts with 30% silver contained. Easy-to-wire design. This Limit Switch can be widely used in various mechanical to monitor the position of moving parts of machines and control circuit and auxiliary circuit for terminal limit protection.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	WMHX
Features	Indicator Light
MPN	1
Operation Method	Combination
Type	Solenoid Electromagnet
Color	Blue
Model	64 x 28 x 25mm (LWT)
Smart Home Compatibility	ADT Pulse
Country/Region of Manufacture	China
Maximum Amperage	5A
Termination Type	3.5mm Jack
Smart Home Protocol	Ethernet
Switch Style	Combination
Finish	Stainless Steel
Current Type	AC/DC
Suitable For	Interior
Application	Commercial
Coil Voltage	5A 250V AC / 0.4A 115V DC
Material	Metal
Current Rating	1-15 A
