Mega 2560 R3 Rev3 Atmega2560-16au Board Usb Cable Compatible For Arduino Jl

US $270

HongKong, Hong Kong
Jun 9th

Open on mobile:
QR code

high quality, Fast delivery,Considerate service Home & Furniture Health & Beauty Computers& Networking Clothes& Accessories Vehicle Parts Sporting Goods UK Warehouse Pictures Specifications Features: The Mega 2560 is a microcontroller board based on the ATmega2560 (datasheet). It has 54 digital input/output pins (of which 15 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Mega is compatible with most shields designed for the Duemilanove or Diecimila. The Mega 2560 is an update to the Mega, which it replaces. The Mega2560 differs from all preceding boards in that it does not use the FTDI USB-to-serial driver chip. Instead, it features the ATmega16U2 (ATmega8U2 in the revision 1 and revision 2 boards) programmed as a USB-to-serial converter. Revision 2 of the Mega2560 board has a resistor pulling the 8U2 HWB line to ground, making it easier to put into DFU mode. Revision 3 of the board has the following new features: 1.0 pinout: added SDA and SCL pins that are near to the AREF pin and two other new pins placed near to the RESET pin, the IOREF that allow the shields to adapt to the voltage provided from the board. In future, shields will be compatible both with the board that use the AVR, which operate with 5V and with the Due that operate with 3.3V. The second one is a not connected pin, that is reserved for future purposes. Stronger RESET circuit. Atmega 16U2 replace the 8U2. Schematic, Reference Design & Pin Mapping EAGLE files: -mega2560_R3-reference-design.zip Schematic: -mega2560_R3-schematic.pdf Pin Mapping: PinMap2560 page Specifications: Microcontroller ATmega2560 Operating Voltage: 5V Input Voltage (recommended): 7-12V Input Voltage (limits) : 6-20V Digital I/O Pins: 54 (of which 15 provide PWM output) Analog Input Pins: 16 DC Current per I/O Pin: 40 mA DC Current for 3.3V Pin: 50 mA Flash Memory: 256 KB of which 8 KB used by bootloader SRAM: 8 KB EEPROM: 4 KB Clock Speed: 16 MHz Power The Mega can be powered via the USB connection or with an external power supply. The power source is selected automatically External (non-USB) power can come either from an AC-to-DC adapter (wall-wart) or battery. The adapter can be connected by plugging a 2.1mm center-positive plug into the board's power jack. Leads from a battery can be inserted in the Gnd and Vin pin headers of the POWER connector. The board can operate on an external supply of 6 to 20 volts. If supplied with less than 7V, however, the 5V pin may supply less than five volts and the board may be unstable. If using more than 12V, the voltage regulator may overheat and damage the board. The recommended range is 7 to 12 volts. Package includes: 1 x ATmega2560-16AU Board 1 x USB Cable Note: A. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. B. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Shipping Options All the items will be dispatched within 1 business day by Airmail after the payment is clear. Items will arrive in 7-25 business days. The arrival time depends on some factors and different areas: Country Delivery Time Working Days (not including holiday) 5-7 8-11 12-14 15-19 20-22 >22 Working Days + Saturday + Sunday 5-9 10-15 16-20 21-25 26-30 >31 United States Rate (item arrived) 5 .1% 50.1% 29.6% 10.5% 4.7% Refund United Kingdom Rate (item arrived) 9.9% 63.2% 19.1% 3.4% 4.4% Refund Australia Rate (item arrived) 21.4% 50.0% 14.3% 7.2% 7.1% Refund France Rate (item arrived) 10.5% 28.6% 43.8% 10.1% 7.0% Refund Germany Rate (item arrived) 11.1% 22.2% 30.3% 20.9% 15.5% Refund Canada Rate (item arrived) 0.0% 47.1% 31.4% 17.6% 3.9% Refund Spain Rate (item arrived) 3.5% 25.0% 47.9% 12.9% 10.7% Refund Please choose some local sellers, if you cannot wait patiently in the shipping time we declared. Once you purchase, please DON'T leave negative or neutral feedback if you haven't received item in 30 days, because we have mentioned the shipping time repeatedly. Notice
