Mf | Mumetall | Shielding Film Mcl61 | Width 61 Cm | 1 Meter | Electrosmog

US $94.34

Ruhstorf, Germany
Jan 30th

Open on mobile:
QR code

MF | Mumetall | Shielding film MCL61 | Width 61 cm | 1 meter MCL61 is our novel magnetic shielding film made from an amorphous cobalt alloy for shielding of low-frequency alternating magnetic fields. Also shields low-frequency electric alternating fields (LF) and high-frequency fields (HF). Statical magnetic fields: Other than stated in the headline, this product is not MUMETALL®. We are utilizing a newer alloy which provides a better shielding. MUMETALL® is promoted to shield statical magnetic fields, refered to the usually used foils (material thickness 0.1 mm) the effect of the shielding is quite low indeed. We are using cobalt based alloy which attenuation is increasing from strength to strength of the velocity of the magnetic fields. There are no velocities by statical magnetic fields or by permanent magnets, that is why this product won´t shield those. In comparison with MUMETALL® our new MCL61 has many advantages: MUMETALL® is soft and sensitive, on bending, to shocks and on processing it looses the attenuation very fast. The cobalt strips in our MCL61 are flexible but hard even at small bending radii. The attenuation remains constant even at high mechanical stress. Because the cobalt strips are only 20 µm thin, 50 mm width and sharp like a knife, we laminate it for protection. Due to the lamination MCL61 is corrosion-resistant even in humid environments. With a width of 61 cm big areas are shielded faster compared to 15 cm width MUMETALL®-strips. MCL61 can easily be cut with scissors. Technical data Width: 61 cm Length: By the meter / 20 m roll / 290 m roll; Because of the high production costs, we allow to divide up the ordered quantity! Attenuation LF magnetic field: 30 dB (97 %); The attenuation depends on the number of phases, cable twisting, the size of the area, etc.; Work in large areas: Shield cables with 1-2 sheets, fuse-boxes with 2-4 sheets; Attenuation HF: 75 dB Weight: 265 g/m²; Material thickness: 0.1 mm; Color: Silver Permeability: µ 4 = 25,000; µ max. = 100,000; Saturation polarization: 0.55 T Materials: Polyester, Co69, Fe4, Mo4, Nb1, Si16, B7 Processing Warning: The cutting edges are sharp like a knife! Important: Its difficult to glue the film free of creases, best cover the area with solid wall coverings. Wall, ceiling, floor: Best use a high-viscous assembly adhesive, that adheres to non-absorbent substrates. Smooth the glue, lay up the film, smooth with a pressure roller or squeegee. The sheets of MCL61 should be overlapped, level out the overlappings, paint it over with any commercial synthetic dispersion paint. Please pay attention that the film is a steam brake on wall areas! Grounding MCL61 is electrically isolated. To ground it, every strip has to be screwed with a chopper disk, that penetrates the polyester film. The grounding set MCL contains all for 10-20 strips. Shielding attenuation The shielding attenuations are regularly tested in our own laboratory, HF due to ASTM D4935-10, the LF magnetic field due to ASTM A698/A698M-07. You find the test report above. Example of use Order quantityIn measures of 1.0 running meters. This product is cut off according to your specifications, a return is not possible. Please request a free sample before an order. Screening attenuationAttenuation values applies to 1 Ghz. Measurement to ASTM D4935-10, IEEE Std 299-2006, IEEEE Std 1128-1998, ASTM A698/A698M-07. ApplicationFloor, Ceiling, Magnetic field, Wall exterior, Wall interior Field typeMF (magnetic fields) AttenuationNormal (up to 30 dB) EcologyNormal ColorSilver Application: YSHIELD produce and trade (with) products for the shielding and measuring of electromagnetic fields (electrosmog). All products belong to this purpose or are accessories for others. If the application is not clear to you, please fill in our contact form or please call us at 0049-8531-31713-0 from 8 am to 5 pm CET. Free catalog: We cannot accept returns of customer-specific cuts (products ordered per linear meter). So please order our free catalog, the included samples will help you to order the correct product. Further documentation: Please find measurement reports (attenuation), technical data sheets, product manuals, etc. on our website at yshield-com eBay shops, supplying countries, taxes: For a better overview of our products please visit our Ebay-Shops: eBay.DE (Deutsch): Bruttopreise in EUR inklusive Steuer. Lieferung nur in der EU. eBay.DE (English): Gross prices in EUR including taxes. Delivery inside the EU. eBay.CO.UK: Gross prices in GBP including taxes. Delivery inside the EU. eBay.COM: Net prices in USD plus taxes. Delivery in all countries outside the EU.
