Microwave Sweep/signal Generator, 1.06 To 2.06 Ghz, 8 +/- 1 Dbm

US $130.49

Albuquerque, New Mexico, United States
Jan 29th

Open on mobile:
QR code

Shown in Images 1 through 7 is a Microwave Generator producing 8 +/- 1 dBm at frequencies from 1.06 to 2.06 GHz on the front panel SMA connector. For additional technical click on this URL, http://www.azdtechnology.com/gax.htm . For CW and swept frequency applications, the front panel dial is used to set the center frequency (CF). To generate a swept frequency (Delta F), connection of a triangle waveform from a function generator to the Generator back panel BNC connector is required. The MGA2K is supplied with a 36-inch length DC power cable permanently attached to the MGA2K for connection to the 11K18 DC power supply (available at this ebay store). See Image 8 for details. Figure 5 shows the location on the chassis back panel of the DC power connections. +18 VDC (Green) and -18 VDC (Yellow) connect to the chassis back panel feed-thru terminals, and common ground (black) is connected to a solder lug located on the lower center of the chassis back panel. The following information applies to Domestic and International Mail. This item will be mailed to the buyer in a 9 X 6 X 4 cardboard box. See Image 9 & 10 for package information. Click on this URL, http://www.usps.com/, for additional USPS Domestic and International shipping information. This is a Category 1 Item >>> PURCHASING MORE THAN 1 ITEM <<< For a sizeable reduction in Postage/Handling Cost, fill your shopping cart and wait 1 day or less for an invoice

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	MGA2K
Manufacturer	AZD TECHNOLOGY
Country of Manufacture	United States
