Minebea Astrosyn Stepper Motor Neugart Gearbox And Gear 23km 304 Dc Stepping

US $199.00

Venice, Florida, United States
Jan 29th

Open on mobile:
QR code

Minebea Astrosyn Stepper Motor Type 23KM K304 with Neugart Planetary Gearbox PLE-40-4 Available with two style gears on two shafts. 1 inch or 1/2 inch gear This is the lowest gear ratio (4:1) available so it is used for slow precise movement ADDITIONAL PICTURES AVAILABLE ? Condition: Used - TESTED Working Great, Runs smooth ? Content: One Stepper Motor + Planetary Gearbox with Gear Specifications :Neugart Planetary Gearbox with gear Brand / Manuf. : Neugart Company Gearbox code PLE 40-4 Number of gear stages 1 Ratio[a] 4 Nominal (rated continous duty) Output torque T2N[c][e] 15.0 Nm Output torque sustainable 30,000 output shaft rotations[c][e][g] 24.0 Nm Mass moment of inertia [i] 0.022 kgcm2 Max. radial load 10.000 h 200 N Max. axial load 10.000 h 200 N Max. radial load 30.000 h 160 N Max. axial load 30.000 h 160 N Weight 0.35 kg Max.recommend input speed 18000 min-1 Recommended max. mean input speed at 50% rated continuous duty torque (S1) 5000 min-1 Recommended max. mean input speed at 100% rated continuous duty torque (S1) 5000 min-1 Efficiency at full load 96% Standard backlash < 15 arcmin Torsional stiffness 1,0 N/arcmin Min. operating temp.[d] -25° C Max. operating temp.[d] +90° C Protection class IP 54 Lubrication lifetime lubrication Gearbox life at full load 30.000 h Running noise[h] 58 db(A) Mounting position any Recommended motor flange / shaft tolerance DIN 42955-N Emergency stop torque [f] 2 - times T2N Type-Size Overall length L1 93.5 mm Main-body length L2 39 mm Legend: [a] Ratio (i=n1 rpm high speed side/n2 rpm low speed side) [b] Number of gear stages [c] Values reference output shaft speed n2=100 rpm, S1= 100% duty cycle, KA=1 application factor and T=30°C, 86 F ambient temperature [d] Measured at the middle of the gearbox housing surface [e] Dependent on the motor shaft diameter [f] Permissible about 1000 times during the gearbox life [g] Permissible for 30,000 output shaft revolutions [h] Sound pressure level measured 1 m from the gearbox for ratio 5:1 at 3000 input rpm and no load [i] The moment of inertia relates to the high speed side (typically motor shaft) I have access to approx 10 more of this item. Returns accepted within 7 days

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Minebea Astrosyn
MPN	23KM 304
Model	Stepper Motor 23KM 304
