Mini-circuits Cbl-1.5ft-smsm+ Used Working Condition

US $55

Niagara Falls, New York, United States
Mar 2nd

Open on mobile:
QR code

Notes A. Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document. B. Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions. C. The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ CBL-1.5FT-SMSM+ 50 ? 1.5FT DC to 18 GHz Test Cable REV. H M121372 ED-11835A CBL-1.5FTSMSM+ BC/TD/CP/AM 131112 Typical Performance Data Outline Dimensions ( ) inch mm Connectors Model Price Qty. Conn1 Conn2 SMA-MALE SMA-MALE CBL-1.5FT-SMSM+ $71.95 ea. (1-9) Features • RoHS compliant • wideband coverage, DC to 18 GHz • extra rugged construction with strain relief for longer life • stainless steel SMA connectors for long mating-cycle life • useful over temperature range, -55°C to 105°C • triple shield cable for excellent shielding effectiveness • flexible for easy connection & bend radius • superior stability of insertion loss, VSWR & phase vs. flexing • 6 month guarantee* Applications • high volume production test stations • research & development labs • environmental & temperature test chambers • replacement for OEM test port cables • field RF testing • cellular infrastructure site testing CBL-1.5FT-SMSM+ INSERTION LOSS 0.00 0.20 0.40 0.60 0.80 1.00 1.20 0 3000 6000 9000 12000 15000 18000 FREQUENCY (MHz) INSERTION LOSS (dB) Frequency (MHz) Insertion Loss (dB) Return Loss (dB) SMA-MALE SMA-MALE T E S T F L E X ™ Maximum Ratings Operating Temperature -55°C to 105°C Storage Temperature -55°C to 105°C Outline Drawing Shielding Effectiveness >100 dB Power Handling at 25°C 891W Max. at 0.4 GHz 539W Max. at 1 GHz 363W Max. at 2 GHz 180W Max. at 6 GHz 117W Max. at 12 GHz 88W Max. at 18 GHz Jacket Clear FEP CBL-1.5FT-SMSM+ RETURN LOSS 0 10 20 30 40 50 60 0 3000 6000 9000 12000 15000 18000 FREQUENCY (MHz) RETURN LOSS (dB) SMA-MALE SMA-MALE CASE STYLE: GM1006-1.5 50.00 0.03 44.38 43.98 Mini-Circuits CBL-1.5FT-SMSM+ Used Working Condition Guaranteed NOT DOA

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	W L Gore
Model	65474
