Mini Circuits ZFSC-2-4 Power Splitter/Combiner, US $24.99 – Picture 0
Mini Circuits ZFSC-2-4 Power Splitter/Combiner, US $24.99 – Picture 0

Mini Circuits Zfsc-2-4 Power Splitter/combiner

US $24.99

  • United States
  • Mar 12th
Open on mobile:
QR code
ITEMS ARE NOT RETURNABLE NOT ACCEPTED Power Splitter/Combiner SELLING MINI CIRCUITS ZFSC-2-4 USED Features • wideband, 0.2 to 1000 MHz • low insertion loss, 0.5 dB typ. • good isolation, 25 dB typ. • excellent amplitude unbalance, 0.1 dB typ. • excellent phase unbalance, 0.5 deg. typ. • rugged shielded case Applications • cellular • VHF/UHF • instrumentation ITEMS ARE NOT RETURNABLE NOT ACCEPTED Coaxial Typical Performance Data Maximum Ratings Operating Temperature -55°C to 100°C Storage Temperature -55°C to 100°C Power Input (as a splitter) 1W max. Internal Dissipation 0.125W max. Outline Drawing Outline Dimensions ( i n c h ) mm electrical schematic REV. B M108294 ZFSC-2-4 HY/TD/CP/AM 080225 Features • wideband, 0.2 to 1000 MHz • low insertion loss, 0.5 dB typ. • good isolation, 25 dB typ. • excellent amplitude unbalance, 0.1 dB typ. • excellent phase unbalance, 0.5 deg. typ. • rugged shielded case Applications • cellular • VHF/UHF • instrumentation Coaxial Connections SUM PORT 3 PORT 1 1 PORT 2 2 CASE STYLE: K18 Connectors Model Price Qty. BNC ZFSC-2-4+ $55.95 (1-9) SMA ZFSC-2-4-S+ $60.95 (1-9) N-TYPE ZFSC-2-4-N(+) $60.95 (1-9) BRACKET (OPTION "B") $2.50 (1+) ZFSC-2-4 INSERTION LOSS 3.0 3.2 3.4 3.6 3.8 4.0 0 200 400 600 800 1000 FREQUENCY (MHz) INSERTION LOSS (dB) S-1(dB) S-2(dB) ZFSC-2-4 ISOLATION 20 25 30 35 40 45 50 0 200 400 600 800 1000 FREQUENCY (MHz) ISOLATION (dB) ZFSC-2-4 VSWR 1.0 1.1 1.2 1.3 1.4 1.5 0 200 400 600 800 1000 FREQUENCY (MHz) VSWR #S-VSWR #1-VSWR #2-VSWR Electrical Specifi cations Frequency (MHz) Insertion Loss (dB) Amplitude Unbalance (dB) Isolation (dB) Phase Unbalance (deg.) VSWR S VSWR 1 VSWR 2 S-1 S-2
