Mitutoyo 543-793 Absolute Digimatic Indicator, Id-s-type, Lug Back, #4-48 Unf

US $330

USA, United States
May 27th

Open on mobile:
QR code

Mitutoyo 543-793 Absolute Digimatic Indicator, ID-S-Type, Lug Back, #4-48 UNF Thread, 3/8" Stem Dia., 0-0.5" Range, 0.0001" Resolution, +/-0.00012" Accuracy, Meets IP42 Specifications Item Description Electronic indicator measures 0 to 0.5" (0 to 12.7mm) with 0.0001" (0.001mm) resolution and + or - 0.00012" accuracy, for measuring short, linear distances in mechanical engineering, machining, and manufacturing applications LCD displays in both inches and metric units, and indicator has a lug back for mounting from the rear of the indicator Absolute electrostatic capacitance-type linear encoder for accurate measurements 3/8" diameter stem and a #4-48 UNF contact point thread mount Ingress Protection certified IP42 for protection against objects greater than 1mm and dripping water Features The Mitutoyo 543-793 Absolute Digimatic electronic indicator gauge, ID-S series, is for measuring short, linear distances in mechanical engineering, machining, and manufacturing applications. It has a measurement range of 0 to 0.5" (0 to 12.7mm), a resolution of 0.0001" (0.001mm), and an accuracy of + or - 0.00012". The LCD displays in both inches and metric units. This model has a lug back for mounting from the rear of the indicator. An Absolute electrostatic capacitance linear encoder helps prevent overspeed errors for taking accurate measurements. This unit has a 3/8" diameter stem and a #4-48 UNF contact point thread mount. This model is Ingress Protection certified IP42 for protection against objects greater than 1mm and dripping water. Additional functions for this indicator include origin set, zero set, counting direction switching, and alerts for low voltage, counting value composition error, and overflow error. The measuring force is 2.0 Newtons (N) or less. It has a battery life of approximately 20,000 hours of normal use. This unit comes with an SR-44 battery. This gauge offers serial data output (using optional SPC cables, sold separately), which increases speed and reliability of digital measurement records. Specifications Range 0 to 0.5" (0 to 12.7mm) Resolution 0.0001" (0.001mm) Accuracy + or - 0.00012" Measuring force 2.0N or less Stem 4-48UNF contact point thread mount with 3/8" diameter spindle Face LCD displays in both inches and metric units, with lug back Data output Yes Dimensions 103.9 x 59 x 27.5mm (H x W x D), not including lug Shipping weight 0.5lb. Standards IP42 Power source SR-44 battery (included) H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Dial indicators are also called dial gauges, probe, and electronic indicators. These precision instruments measure small linear distances and object sizes. The dial magnifies the measurement so that it can be easily read by the human eye. Frequently used in manufacturing, laboratories, and other industrial or mechanical fields, dial indicators are used anywhere a small measurement must be found and recorded or transferred, such as checking the variation in tolerance of a workpiece. Standard dial indicators measure the displacement along the axis of the indicator. Dial test indicators are very similar to dial indicators, except that the axis of measurement is perpendicular to the axis of the indicator. Dial and dial test indicators can be analog, with a mechanical dial, or electronic, with a digital display. Some electronic models transfer the data electronically to a computer for recording and potential manipulation. Mitutoyo manufactures precision measuring tools, metrology equipment, and related systems. The company, founded in Tokyo in 1934, formed Mitutoyo America Corporation in 1963 with headquarters in Aurora, IL. What's in the Box? Mitutoyo 543-793 indicator gauge SR-44 battery Additional Information Manufacturer: Mitutoyo Shipping Weight: 70 Product Dimensions: Width: 4.20 Length: 7.50 Height: 3.00 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
