Home Payment Shipping Warranty & Guarantee Feedback&Cantact Return Policy Store search Store category You may also like We Are Your Best Choice! High Quality and 100% Service! Product Description Features 6.1 Operates with ATmega328 microcontrollers. 6.2 Displaying the results to a 128x64 graphic LCD-Display. 6.3 One key operation with automatic power shutdown. 6.4 Shutdown current is only about 20nA. 6.5 Automatic detection of NPN and PNP bipolar transistors, N- and P-Channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. 6.6 Automatic detection of pin layout of the detected part. 6.7 Measuring of current amplification factor and Base-Emitter threshold voltage of bipolar transistors. 6.8 Darlington transistors can be identified by the threshold voltage and high current amplification factor. 6.9 Detection of the protection diode of bipolar transistors and MOSFETs. 6.10 Measuring of the Gate threshold voltage and Gate capacity value of MOSFETs. 6.11 Up to two Resistors are measured and shown with symbols and values with up to four decimal digits in the right dimension. All symbols are surrounded by the probe numbers of the Tester (1-3). So Potentiometer can also be measured. If the Potentiometer is adjusted to one of its ends, the Tester cannot differ the middle pin and the end pin. 6.12 Resolution of resistor measurement is now up to 0.01Ω, values up to 50MΩ are detected. 6.13 One capacitor can be detected and measured. It is shown with symbol and value with up to four decimal digits in the right dimension. The value can be from 25pF to 100mF. The resolution can be up to 1pF . 6.14 For capacitors with a capacity value above 0.18µF the Equivalent Serial Resistance (ESR) is measured with a resolution of 0.01Ω and is shown with two significant decimal digits. 6.15 For capacitors with a capacity value above 5000pF the voltage loss after a load pulse can be determined. The voltage loss give a hint for the quality factor of the capacitor. 6.16 Up to two diodes are shown with symbol or symbol in correct order. Additionally the flux voltages are shown. 6.17 LED is detected as diode, the flux voltage is much higher than normal. Two-in-one LEDs are also detected as two diodes. 6.18 Zener-Diodes can be detected, if reverse break down Voltage is below 4.5V. These are shown as two diodes, you can identify this part only by the voltages. The outer probe numbers, which surround the diode symbols, are identical in this case. You can identify the real Anode of the diode only by the one with break down (threshold) Voltage nearby 700mV! 6.19 If more than 3 diode type parts are detected, the number of founded diodes is shown additionally to the fail message. This can only happen, if Diodes are attached to all three probes and at least one is a Z-Diode. In this case you should only connect two probes and start measurement again, one after the other. 6.20 Measurement of the capacity value of a single diode in reverse direction. Bipolar Transistors can also be analysed, if you connect the Base and only one of Collector or Emitter. 6.21 Only one measurement is needed to find out the connections of a bridge rectifier. 6.22 Capacitors with value below 25pF are usually not detectet, but can be measured together with a parallel diode or a parallel capacitor with at least 25pF. In this case you must subtract the capacity value of the parallel connected part. 6.23 For resistors below 2100Ω also the measurement of inductance will be done, if your ATmega has at least 16K flash memory. The range will be from about 0.01mH to more than 20H, but the accuracy is not good. The measurement result is only shown with a single component connected. 6.24 Testing time is about two seconds, only capacity or inductance measurement can cause longer period. 6.25 Software can be configured to enable series of measurements before power will be shut down. 6.26 Selectable facility to calibrate the internal port resistance of port output and the zero offset of capacity measurement with the selftest . A external capacitor with a value between 100nF and 20µF connected to pin 1 and pin 3 is necessary to compensate the offset voltage of the analog comparator. This can reduce measurement errors of capacitors of up to 40µF. With the same capacitor a correction voltage to the internal reference voltage is found to adjust the gain for ADC measuring with the internal reference. 10 6.27 Display the Collector cutoff current ICE0 with currentless base (10µA units) and Collector residual current ICES with base hold to emitter level . This values are only shown, if they are not zero (especially for Germanium transistors). 6.28 Thyristors and Triacs can only be detected, if the test current is above the holding current. Some Thyristors and Triacs need as higher gate trigger current, than this Tester can deliver. The available testing current is only about 6mA! Attention: Allways be shure to discharge capacitors before connecting them to the Tester! The Tester may be damaged before you have switched it on. There is only a little protection at the ATmega ports. Extra causion is required if you try to test components mounted in a circuit. In either case the equipment should be disconnected from power source and you should be shure, that no residual voltage remains in the equipment. note : the battery is not include because of air shipping free shipping with tracking number package include : 1pcs MK-328 TR ESR transistor 1pcs Test clips 3pcs test cable Payment Shipping Warranty & Guarantee Feedback&Cantact Return Policy Payment We accept Paypal only, It is fast, easy and safe. Payment must be completed within 7 days. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCAL TAXES OR ANY OTHER IMPORTATION FEES. Shipping 1. All items will be shipped to buyer's ebay address. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. 2. We usually ship within 1 business day (weekends and public holidays are not recognized as business days) after full payment is received and cleared. Generally, delivery time is 9-35 days. (Other countries or remote areas may take longer.) 3. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Warranty & Guarantee Good good quality. Buy with confidence! 14 days returned or more Guarantee. If not satisfied with the item, you can choose to return it for a replacement or money back. Please contact me before you return it. full refund after we receive our original item. We maintain high standards of excellence and strive for 100% customer satisfaction! Positive feedback is very important to us. We request that you contact us BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns Feedback&Cantact 1. We care about our valued buyers, Please contact us through email with any questions or concerns. We will reply to messages within 2 business days. Emails, which are received during the weekend, will be replied on Monday. If you do not received a response in expected time period from us, please check your junk or spam mailbox. 2. Our goal is to make sure you are a happy buyer and have a pleasant shopping with us. If you are happy with our item and service, please do leave us positive feedback and 5 star rate. Please email us before leaving any 1 or 2 ratings, neutral or negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. We thank you for your effort to make this sale and purchase experience a happy one! Return Policy 1. We are committed to give you the best customer service possible. If for any reason you are dissatisfied with a purchase, please contact us and we'll assist you with a prompt solution. We'd like to settle any problem in a friendly manner. 2. We want to make sure you are happy with our item. If for any reason you wish to return the item, contact us within 14 days from the delivery date and we will give you a full refund or exchange. Only unused, undamaged and original condition item can be qualified for a return. Buyer is responsible for return shipping fee. 3. We will not be liable to customer for any damages beyond the amount of money that customer has actually paid us.
