Module Zvs Board Induction Heating 1 Pcs 20a Board Driver High Quality

US $18.00

suzhou, China
Aug 24th

Open on mobile:
QR code

Product Description Module ZVS Board Induction Heating 1 Pcs 20A Board Driver High Quality Features: 100% brand new and high quality Made of high-quality materials, durable The ZVS board uses a high-quality 1.6mm double-layer glass fiber board, a large inductance coil and a stable 5-band resistor to ensure its stable performance. With the right power source and the right circuit, you can create a beautiful arc yourself. This is a popular board, you can buy one yourself, or you can give it as a gift to electronics enthusiasts. It can be used for hardening, annealing and other heat treatment of small parts DIY player, Can also be used with graphite crucibles for melting gold, silver, copper, aluminum and other metals The driver module is made of a high standard 1.6mm double-layer glass fiber board to improve durability The factory-customized large inductance coil is wound with 1.2mm copper wire, which has more stable performance and more consistent parameters The ZVS driver module uses 5-band resistors to achieve smaller errors and stable performance More tin is added to the bottom of the board, so the driver board can be used for induction heating without burning out Use 12-30V DC power supply with current greater than 10A. The higher the voltage, the longer the arc (tested on a 27V/15A power supply, it can produce an arc of 80mm length). As an induction heating plate, the higher the voltage, the faster the heating speed and the higher the temperature. The recommended heating object diameter is less than 2/3 of the coil. Product parameters: Name: ZVS board Material: plastic, metal Voltage: DC12V-30V Maximum. Current: 20A Maximum. Power: 1000W Dimensions: 69 x 85 x 30mm / 2.71 x 3.34 x 11.81" notes: 1. The kit contains a complete set of drive circuit components and brass 2. Buyers need to provide their own power supply and cooling device. 3. The circuit board adopts double-sided glass fiber board, mainly copper traces are used to widen the entire back of the resonant circuit, and work continuously. Please add a fan to blow it from above to dissipate the resonant capacitor and other components. 4. When using a switching power supply, please note that since high power generally has a slow start function, the output voltage of the machine that has just been turned on rises slowly, and before the induction heating circuit is turned on, if the voltage rises to 12V, it cannot vibrate due to insufficient starting voltage , Resulting in the burning of two MOS tubes that are conducting at the same time. So first, the voltage of the switching power supply will be increased to above 12V, and then it will enter the induction heating circuit. 5. The volume of the heated object inside the heating coil cannot exceed 1/5 of the volume (if it is a heating cylinder, the diameter of the heating coil is less than 1/3 of the diameter), otherwise it may be due to overload or burnt out the power supply of the circuit. Although the circuit can withstand the input current torque of 20-30A, it does not exceed 15A when working safely. You can easily add an ammeter between the power supply and the heating driver board, but always monitor the current overload. Package list: 1 *ZVS board Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Maximum. Current	20A
MPN	Does Not Apply
Maximum. Power	1000W
Type	ZVS board
Dimensions	69 x 85 x 30mm / 2.71 x 3.34 x 11.81
Package list	1 *ZVS board
Name	ZVS board
Material	plastic, metal
Package Contents	1 *ZVS board
Voltage	DC12V-30V
UPC	Does not apply
