Motor Control Development Board Dual H-bridge Driver L293d For Dc&stepping Motor

US $9.99

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

This auction is for Motor Control Board Motor Control Board, drives DC Motors & Stepping Motors Features Onboard dual H-bridge driver L293D drives 2 DC motors or 1 stepping motor at one time 600mA output current (peak 1.2A) per single bridge ESD protection 5V operating voltage, motor drive voltage 4.5V-36V Output via screw terminals, easy connection Dimension : 43mm*27mm Mounting hole size : 2mm Storage temperature : -25°C ~ +130°C How to Use M1A/M1B : connects to MCU digital IO, motor1 rotation controlling M2A/M2B : connects to MCU digital IO, motor2 rotation controlling GND : ground VCC : 5V power supply M1A/M2A M1B/M2B M1/M2 1 0 Counterclockwise/Clockwise 0 1 Clockwise/Counterclockwise 1 1 Stop 0 0 Stop Note : the motor rotate directions depend on the connections. Photos Package Contains Motor Control Board x 1 Downloads Development resources: demo codes, schematic, datasheets, etc. Click here to download Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Storage temperature	-25°C ~ +130°C
Model	Motor Control Board
Dimension	43mm*27mm
Country/Region of Manufacture	China
Feature	drives 2 DC motors or 1 stepping motor at one time
Onboard driver	dual H-bridge driver L293D
