MOTOROLA 2N3324 GERMANIUM PNP TRANSISTOR TO-18 OLD GOLD (1PC), US $9.95 – Picture 0
MOTOROLA 2N3324 GERMANIUM PNP TRANSISTOR TO-18 OLD GOLD (1PC), US $9.95 – Picture 0

Motorola 2n3324 Germanium Pnp Transistor To-18 Old Gold (1pc)

US $9.95

  • Stanton, California, United States
  • Aug 25th
Open on mobile:
QR code
MOTOROLA 2N3324 GERMANIUM PNP TRANSISTOR TO-18 OLD GOLD (1PC) NEW OLD STOCK LOT  32110  F27 Characteristic Specifications SEMICONDUCTOR MATERIAL GERMANIUM INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 35.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 35.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 3.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 100.00 MILLIAMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 150.0 MILLIWATTS MAXIMUM COLLECTOR POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 100.0 DEG CELSIUS JUNCTION INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR MOUNTING METHOD TERMINAL TERMINAL LENGTH 0.500 INCHES MINIMUM TERMINAL CIRCLE DIAMETER 0.100 INCHES NOMINAL TERMINAL TYPE AND QUANTITY 3 UNINSULATED WIRE LEAD OVERALL LENGTH 0.210 INCHES MAXIMUM OVERALL DIAMETER 0.230 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: PNP (NON-CORE DATA) SPECIFICATION/STANDARD DATA 80131-RELEASE4694 PROFESSIONAL/INDUSTRIAL ASSOCIATION SPECIFICATION
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Mounting Style Through-Hole
MPN 2N3324
Number of Pins 3
Brand Motorola
Series 2N3324
Package/Case TO-18
Type PNP
