Moxa Vport 461 461-t Video Encoder

US $549.00

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

The VPort 461 1-channel industrial video encoder with H.264 video compression algorithm provides the best video quality on the market, but with a smaller bandwidth requirement than other video compression standards. In addition, to meet various video stream requirements, the VPort 461 can provide up to 3 video streams simultaneously with H.264 and MJPEG compression format. Video streams can be used for different purposes, such as viewing, recording, and analyzing, and the industrial rugged design, which includes a -40 to 75°C operating temperature, IP30 form factor protection, and industrial certifications, make the VPort 461 suitable for harsh environments.Three simultaneous video streams for H.264 and MJPEG Video stream up to 30/25 frames/sec at full D1 (NTSC:720 x 480; PAL:720x576) resolution Video latency under 200 ms 2 Ethernet ports for cascade and Ethernet port redundancy Local storage capability with SD card slot Industrial design with -40 to 75°C operating temperature Free VPort SDK PLUS supported Video: Video Compression H.264 (MPEG4 part 10), MJPEG Video Inputs 1, BNC connector Video Outputs via Ethernet NTSC/PAL Auto-sensing or manual Video Viewing Adjustable image size and quality Timestamp and text overlay Video Stream Maximum provide 3 video streams (2 Encoders, 1 Encoder for H.264, the other for H.264 and MJPEG) Video Resolution and FPS (frames per second) Audio: Audio Input 1 Line-in or MIC-in with 3.5 mm phone jack Audio Output 1 Line out with 3.5 mm phone jack Network: Protocols TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, UPnP, RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS Ethernet 2 10/100BaseT(X) auto negotiating RJ45 ports Serial: PTZ Port 1, RS-232/422/485 port (terminal block connector), max. speed of 115.2 Kbps, with 15 KV ESD protection Console Port 1 RS-232 RJ45 port COM Ports 1, RS-232/422/485 (DB9 female connector), max. speed of 115.2 Kbps, with 15 KV ESD protection GPIO: Digital Inputs 2, max. 8 mA High: +13V to +30V Low: -30V to +3V Relay Outputs 2, max. 24 VDC @ 1A Local Storage SD Socket Standard SD socket, V2.0 (SDHC) LED Indicators: STAT System boot properly or not PWR1 Power 1 PWR2 Power 2 Fault Can be configured to correspond to system alarm, power failure, video loss, or disconnected network VIDEO Video input signal PTZ PTZ control signal SD SD card mounting or unmounting in successful Physical Characteristics: Enclosure Metal, IP30 protection Dimensions 52.98 x 135 x 105 mm (2.09 x 5.31 x 4.13 in) Installation DIN-Rail mounting, wall mounting (with optional kit) Power Requirements: Input Voltage 2 24 VDC/VAC power inputs for redundancy Power Consumption Approx. 5.5 W Environmental Limits: Operating Temperature Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative Humidity 5 to 95% (non-condensing) Agency Approvals: EMI FCC Part 15, CISPR (EN55022) class A EMS EN61000-4-2 (ESD), level 2 EN61000-4-3 (RS), level 3 EN61000-4-4 (EFT), level 3 EN61000-4-5 (Surge), level 3 EN61000-4-6 (CS), level 3 EN61000-4-8 EN61000-4-11 Safety UL508 (Pending) Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C and D (Pending); ATEX Class I, Zone 2, Ex nC IIC (Pending) Shock IEC60068-2-27 Freefall IEC60068-2-32 Vibration IEC60068-2-6 Traffic Control Complies with NEMA TS2-Section 2 (Pending) Warranty: Warranty Period 5 years Others Alarm Features Video Motion Detection: Includes sensitivity tuning(after firmware V2.0) Video Loss: Video loss alarm Scheduling: Daily repeat timing schedule Imaging: JPEG snapshots for pre/trigger/post alarm images Email/FTP Messaging: Automatic transfer of stored images via email or FTP with event-triggered actions Custom Alarms: HTTP event servers and CGI commands for setting customized alarm actions Pan/Tilt/Zoom PTZ Camera Control: Via RS-232/422/485 PTZ port or COM port PTZ Control Functions: PAN, TILT, ZOOM, FOCUS, moving speed, preset position (max. 25 positions), and 10 custom commands PTZ Function Updates: Driver upload supported Supported Devices and Protocols: Pelco D, Pelco P, Dynacolor DynaDome,Cohu and Custom Camera Transparent PTZ Control: Control PTZ cameras with legacy PTZ control panel or keyboard connected to a PC or VPort decoder Security Password: User level password protection Filtering: By IP address System Requirements CPU: Pentium 4, 2.4 GHz or above Memory: 512 MB memory or above OS: Windows XP/2000 with SP2 or above Browser: Internet Explorer 6.x or above Multimedia: DirectX 9.0c or above Software Bundled Free VPort SDK PLUS: Includes CGI commands, ActiveX Control, and API library for customized applications or system integration for third-party developers (the latest version of SDK is vailable for download from Moxa's website). Specification Power Requirements Power Consumption Approx. 5.5 W Input Voltage 2 24 VDC/VAC power inputs for redundancy Security Password User level password protection Filtering By IP address Alarms Video Loss Video loss alarm Video Motion Detection Includes sensitivity tuning Email/FTP Messaging Automatic transfer of stored images via email or FTP with event-triggered actions Custom Alarms HTTP event servers and CGI events for setting customized alarm actions Scheduling Daily repeat timing schedule Pre-alarm Buffer 24 MB for JPEG snapshot images Imaging JPEG snapshots for pre/trigger/post alarm images PAN/TILT/ZOOM PTZ Control Functions PAN, TILT, ZOOM, FOCUS, moving speed, preset position (max. 25 positions), and 24 custom commands Supported Device Protocols Pelco D, Pelco P, Dynacolor DynaDome, Cohu, Custom Camera Transparent PTZ Control Control PTZ cameras with legacy PTZ control panel or keyboard connected to a PC or VPort decoder PTZ Camera Control Via RS-232/422/485 PTZ port or COM port PTZ Function Updates Driver upload supported Local Storage SD Socket Standard SD socket, V2.0 (SDHC) Environmental Limits Operating Temperature Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative Humidity 5 to 95% (non-condensing) MTBF (mean time between failures) Time 375,000 hours Database Telcordia (Bellcore), GB 25°C Serial Port Console Port 1 RS-232 RJ45 port PTZ Ports 1, RS-232/422/485 port (terminal block connector), max. speed of 115.2 Kbps COM Ports 1, RS-232/422/485 (DB9 female connector), max. speed of 115.2 Kbps GPIO Digital Inputs 2, max. 8 mA High: +13 to +30 V; Low: -30 to +3 V Relay Outputs 2, max. 24 VDC @ 1 A System Requirements CPU Pentium 4, 2.4 GHz or above Browser Internet Explorer 6.x or above Memory 512 MB memory or above OS Windows XP/2000 with SP2 or above Multimedia DirectX 9.0c or above LED Indicators PWR1 Power 1 PWR2 Power 2 SD SD card operation FAULT Can be configured to correspond to system alarm, power failure, or disconnected network VIDEO Video input signal PTZ PTZ control signal Physical Characteristics Weight 900 g Dimensions 52.98 x 135 x 105 mm (2.09 x 5.31 x 4.13 in) Installation DIN-Rail mounting, wall mounting (with optional kit) Housing Metal, IP30 protection Standards and Certifications EMI FCC Part 15 Subpart B Class A, EN 55022 Class A Safety UL 60950-1 Note Please check Moxa's website for the most up-to-date certification status. Shock IEC 60068-2-27 Vibration IEC 60068-2-6 EMS EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8, EN 61000-4-11 Freefall IEC 60068-2-32 Audio Audio Outputs 1 Line-out with 3.5 mm phone jack Audio Format Mono, PCM Audio Inputs 1 Line-in or MIC-in with 3.5 mm phone jack Network Ethernet 2 10/100BaseT(X) auto negotiating RJ45 ports Protocols TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DHCP, UPnP, RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS, Modbus/TCP Warranty Warranty Period 5 years Details See moxa warranty Software Development Kit VPort SDK PLUS Includes CGI commands, ActiveX Control, and API library for customized applications or system integration for third-party developers (the latest version of SDK is vailable for download from Moxa’s website). Standard ONVIF (ONVIF version firmware) Video Video Inputs 1, BNC connector Video Compression H.264 (MPEG4 part 10), MJPEG Video Streams Max. of 3 video streams (2 encoders: 1 for H.264, 1 for H.264 and MJPEG) Video Outputs over Ethernet NTSC/PAL Auto-sensing or manual Video Viewing • Dynastream supported for changing the video frame rate automatically • Adjustable image size and quality • Timestamp and text overlay • Maximum of 10 simultaneous unicast connections

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Moxa
Model	VPort
