N-tron 524tx-a Industrial Ethernet Switch. 24 Port. Rack Mount. Hub. Brand New

US $999.00

Towson, Maryland, United States
Jan 29th

Open on mobile:
QR code

The N-TRON® 524TX Series Industrial Ethernet Switch offers outstanding performance and ease of use. It is ideally suited for connecting Ethernet enabled industrial and/or security equipment and can be optionally configured with advanced Ethernet communication management functions PRODUCT FEATURES • Full IEEE 802.3 and 1613 Compliance • NEMA TS1/TS2 Compliance • American Bureau of Shipping (ABS) Type Approval • Twenty-Four 10/100 BaseTX RJ-45 Ports • -40? to 85?C Operating Temperature • Auto Sensing 10/100BaseTX, Duplex, and MDIX • Store-and-forward Technology • Up to 2.6 Gb/s Backplane Throughput • Rugged Industrial DIN-Rail Enclosure • Redundant Power Inputs (10-30 VDC) • Bi-Color LED's For Link, Speed, Activity & Duplex Status Advanced Management Features (With -A option only): • IGMP Snooping • VLAN • QoS • Trunking • Mirroring • N-ViewTM (Remote Monitoring Using OPC Technology) Advanced Management Functions The 524TX-A offers several management functions that can be easily configured using the COM Port (DB 9 Connector located on the right side of the switch). IGMP Snooping - Internet Group Management Protocol is a feature that allows the 524TX-A switch to forward and filter multicast traffic intelligently. VLAN - Virtual Local Area Network allows segmentation of the switch in order to create two or more separate local area network domains. QoS - Quality of Service provides prioritization of network traffic in order to provide better network service. The primary goal of QoS is to improve the latency of prioritized Ethernet packets required for ring management, real-time and other interactive applications. Trunking - Trunking (aggregation) enables multiple physical ports to be linked together and function as one uplink to another N-TRON trunking capable switch configured in the same manner, thereby increasing the bandwidth between switches. This configuration can provide increased bandwidth and redundancy to applications requiring high levels of fault tolerant operation. Port Mirroring - This 524TX-A function allows the traffic on one port to be duplicated and sent to a designated mirror port. Port mirroring can be used to monitor Ethernet traffic on the designated source port using the assigned mirror port. N-View OPC Switch Monitoring (With -A or -N Option Only) The N-TRON N-View OLE for Process Control (OPC) server software can be combined with popular HMI software packages to add network traffic monitoring, trending and alarming to any application using N-TRON switches configured with the N-View option. N-TRON's N-View OPC Server collects 41 different traffic variables per port and 5 system level variables per switch. This information can provide a complete overview of the network load, service quality, and packet traffic. OPC client software can use N-View OPC Server data to resolve network problems quickly and improve system reliability. Industrial Packaging and Specifications The N-TRON 524TX is designed to operate in industrial environments. It is housed in a rugged steel enclosure that can be DIN-RAIL or panel mounted, and an optional rackmount kit is also available. The 524TX comes standard with extended temperature rating, extended shock and vibration specs, redundant power inputs, and a high MTBF (greater than 2M hours). Ease of Use The N-TRON 524TX requires no setup unless the advanced port functions are utilized. The Twenty-Four 10/100BaseTX ports are auto sensing and auto confi guring. Each copper port is automatically negotiated for maximum speed and performance by default. Bi-color LED's are provided to display the link status, link speed and activity of each port as well as power on/off status. Performance The N-TRON 524TX uses "state of the art" IEEE 802.3 Fast Ethernet 10/100BaseTX switching technology. This technology eliminates network collisions and increases network determinism. Up to 4,000 MAC addresses are supported enabling sophisticated and complex network architectures. A high speed processor and backplane allows wire speed capability on all ports simultaneously. 524TX-A Specifications Switch Properties Number of MAC Addresses: 4,000 Aging Time: 300s (programmable -A) Latency Typ.: 2.1 ?s Backplane Speed: 2.6Gb/s Switching Method: Store & Forward Case Dimensions Height - 1U: 1.75" (4.5cm) Width: 19" (48.3cm) Depth: 4.2" (10.6cm) Weight: 3.7 lbs Electrical Redundant Input Voltage: 10-30 VDC Input Current: 720 mA@24V Inrush: 9.5Amp/0.75ms@24V Environmental Operating Temp: -40oC to 85oC Operating Humidity: 10% to 95% (Non Condensing) Operating Altitude: 0 to 10,000 ft. Reliability MTBF: >1 Million Hours Shock and Vibration Shock: 200g @ 10ms Vibration/Seismic: 50g, 5-200Hz, Triaxial Serial Configuration Port Com Parameters: 9600,n,8,1 Network Media 10BaseT: >Cat3 Cable 100BaseTX: >Cat5 Cable Connectors 10/100BaseTX: Twenty-Four (24) RJ-45 Copper Ports Recommended Wiring Clearance Front: 4" (10.16 cm) Side: 1" (2.54 cm) Regulatory Approvals FCC/CE (CFR 47, Part 15, Subpart B, Class A) EMC Dir 89/336/EEC, EN 50204, EN 55011 EN61000-4-2/3/4/5/6/8/11, EN61000-6-2/4 ANSI C63.4, ICES-003 UL /cUL: Class I, Div 2, Groups A, B, C, D and T4A UL 508 and UL 1604 CAN/CSA-C22.2 No.213, ATEX II 3 G Ex nA ABS Type Approval for Shipboard Applications GOST-R Certifi ed, RoHS Compliant Designed to comply with: IEEE 1613 for Electric Utility Substations NEMA TS1/TS2 for Traffic Control "

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	524TX-A
MPN	524TX-A
