Narda 3096 precision high directivity directional coupler, 7-18 GHz, 10dB, US $170 – Picture 0
Narda 3096 precision high directivity directional coupler, 7-18 GHz, 10dB, US $170 – Picture 0

Narda 3096 Precision High Directivity Directional Coupler, 7-18 Ghz, 10db

US $170

  • Sunnyvale, California, United States
  • Jun 15th
Open on mobile:
QR code
New Page 1 All items in my store are categorized for your convenience. Be sure to take advantage of the store categories (top left of the store page), if you are looking for similar items. For sale is: Narda Microwave 3096 Octave High Directivity Directional Coupler in excellent condition. Very high directivity of 35 dB, and low VSWR. Octave frequency range of 7-18 GHz, -10dB coupling. Input/Output connectors are precision APC-7, coupling connector is N. Please see Narda Microwave East for full specs, this part is current at Narda, (use the product search and enter 3096). Model Number : 3096 Narda High-Directivity Broadband Directional Coupler  Model Number  3096 Frequency (Low) in MHz  7,000 Frequency (High) in MHz  18,000 Nominal Coupling dB  10 Directivity dB (min) 35 VSWR Primary Line (max) 1.25 VSWR Secondary Line (max)  1.3 Frequency Sensitivity dB (max)   +/- 1.5 Absolute Calibration Accuracy dB +/- 0.1 Power in W (Average) 5* Weight (max) in oz  15 Weight (max) in gr  425 Special Notes Primary input and output connectors are 7 mm. Secondary line connectors are Type N female. *Power rating of 5 watts into an open circuited load (VSWR = 8) NOTE: All units are available on a Custom-Order basis. Minimum quantities may apply. Spec Sheet (download)  View PDF  Shipping: I always pack with care to ensure your item arrives in mint condition. To lower your shipping costs, I automatically combine shipping for items purchased on the same day. International customers please contact seller for shipping price before bidding or purchasing. Thank you for your interest! Questions are invited! Please check out my store for similar items    Additional search keywords: directional coupler, power coupler , power divider , power splitter, directivity, reflection, directivity, reflectivity Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
