National Instruments NI 9478, 48 V, Sinking Digital Output, 16 Ch Module, US $1200 – Picture 0
National Instruments NI 9478, 48 V, Sinking Digital Output, 16 Ch Module, US $1200 – Picture 0

National Instruments Ni 9478, 48 V, Sinking Digital Output, 16 Ch Module

US $1200

  • Houston, Texas, United States
  • Jun 3rd
Open on mobile:
QR code
Factory sealed was broken but the module is brand new unused. Comes with the original packaging and the paperwork. 16 channels, 50 µs digital output module Up to 1.2 A per channel (all 16 channels) or 5 A for a single channel Programmable current limits for customizable system protection Designed for solenoid and valve control Onboard system diagnostics and solenoid health monitoring -40 °C to 70 °C operating, 5 g vibration, 50 g shock The NI 9478 is a 16-channel, 50 µs, sinking digital output C Series module with programmable current limits, which provide customizable system protection that is ideal for solenoid and valve control applications. Each channel is compatible with 5 V to 50 V signals and features 1,000 Vrms withstand isolation from channel to earth ground. The NI 9478 can sink up to 16 A of current per module, depending on channel configuration. It uses an industry-standard 37-pin D-SUB connector for low-cost cabling to a wide variety of 37-pin accessories from NI or other vendors. The module also works with industrial logic levels and signals to directly connect to a wide array of industrial relays, solenoids, and motors. Recommended Accessories -NI 9923 front-mount D-SUB to screw terminals  Box Contents -1 NI 9478 C Series module  -1 NI 9478 Operating Instructions and Specifications manual
