National Instruments Pcie-6536 High-speed Digital I/o Board- Lightly Used

US $1500

Rowland Heights, California, United States
Jun 8th

Open on mobile:
QR code

National Instruments PCIe-6535/6/7 high-speed digital I/O board-Used Used: An item that has been used previously but is fully operational and functions as intended. See the seller’s listing for full details and description of any imperfections. Overview NI 6535, NI 6536, and NI 6537 digital I/O devices are high-speed 32-bit interfaces built on PCI Express bus technology. These cost-effective devices provide an ideal way to interface with a variety of digital applications requiring a high number of channels for digital I/O including high-speed functional digital tests, handshaking, chip testing, pattern generation, memory testing, and logic vector capture. This family features maximum clock rates of 10, 25, or 50 MHz; selectable voltage levels compatible with 2.5, 3.3, and 5 V TTL logic; and individually configured pins for input or output. With both synchronous and asynchronous timing modes, handshaking, and a software API designed around the NI-DAQmx driver, NI 6535/36/37 devices have the flexibility to meet the requirements of semiconductor, consumer electronics, and communications applications. 10 MHz maximum clock rate 40 MB/s maximum throughput Selectable voltage levels of 2.5 and 3.3 V (5 V compatible) 32 channels with per-channel directional control Synchronous and asynchronous timing modes Software compatible with NI 6533 and NI 6534 NI-DAQmx applications Requirements and Compatibility OS Information Windows 7 Windows 7 64-bit Windows Server 2003 R2 32-bit Windows Server 2008 R2 64-bit Windows Vista Windows XP Driver Information NI-DAQmx Software Compatibility ANSI C/C++ LabVIEW LabVIEW Base Development System Measurement Studio Measurement Studio .NET Support Visual Studio Visual Studio .NET High-Speed Data Streaming Generate and acquire larger digital waveforms with PCI Express high-speed devices, using the ideal, low-cost NI 6535/36/37 devices Stream continuously at up to 200 MB/s of data Stream data from the host computer’s memory or high-end storage solution such as NI RAID arrays and controllers Use for applications requiring high speeds and fast streaming capabilities such as LCD testing, wireless protocols, ADC/DAC interfacing, or digital pattern capture Visit ni.com/streaming for more information Multidevice Synchronization These products use the PXI trigger bus or RTSI bus to send and receive clock and trigger signals to and from other NI 6535/36/37 devices in your system. With these capabilities, you can create synchronized systems with large numbers of digital I/O lines. Application and Technology Digital Interfacing • Use NI 6535/36/37 devices to interface digital systems and devices directly with PC-based applications • Control, communicate with, or send data to a digital device or system • Analyze and record digital data • Perform bidirectional communications with handshaking Timing Modes • Pattern I/O or sample clock (synchronous) – transfer patterns using an internal or external clock signal • Burst handshaking (synchronous) – handshake an NI 6535, NI 6536, or NI 6537 device and the peripheral device during synchronous transfer to maximize the transfer rate • Handshaking I/O (asynchronous) – transfer patterns when both the NI 6535, NI 6536, or NI 6537 device and the peripheral device are ready • On-demand (unstrobed or static I/O) – acquire or generate data through software-timed commands • Change detection – acquire data whenever a change occurs on one or more digital lines & more information please check with http://www.ni.com/datasheet/pdf/en/ds-114 @Please see the pictures for full details and description of any imperfections. @Ship to 48 continental states only (Excluded PO Boxes, APO/FPO) @Buyers please check your system was compatible before buying/bidding. @If you have any question please email before you buying/bidding. @Seller do not offer return or refund for any reasons: e.g workmanship, performance, appearance, compatibility & lost or any mistake by carrier etc... Buyer must take this rise before buying or bidding. @Please do not leave negative or neutral feedback, or open a case without contacting me first! If you are not satisfied with your purchase in any way, please contact me first! I will do the best I can try to resolve any problems you may have!
