Ne555 Duty Cycle Adjustable Pulse Frequency Square Wave Signal Generator Module

US $2200

Fort Collins, Colorado, United States
Oct 19th

Open on mobile:
QR code

NE555 Duty Cycle Adjustable Pulse Frequency Module Square Wave Signal Generator This NE555 square wave pulse generator module can be used to produce square wave signals for experimental development, or in applications such as driving stepper motors, and as an adjustable pulse for microcontroller (MCU) applications. Only 31mm x 22mm (1.2" x 0.9"), the board features an NE555 timer chip configured in four frequency ranges, 1Hz to 50Hz, 50Hz to 1kHz, 1kHz to 10kHz and 10kHz to 200kHz all adjustable with onboard jumpers and two trim-pots to adjust the output frequency and the duty cycle. Input voltage to the module (VCC) is variable from 5V to 15V DC and draws approximately 15mA at 5v (35mA at 12v) with an output amplitude of 4.2V peak-to-peak to 11.4V peak-to-peak based on the supply voltage. An indicator LED illuminates on a low-level output and flashes relative to the output frequency. At higher frequencies, the LED will appear to be on solid and without a visible flash. Features: Size: 31mm * 22mm Main chip: NE555 Input Voltage (VCC): 5V-15VDC Input current:~100MA Output amplitude: 4.2V V-PP to 11.4V V-PP. (Varries with VCC voltage) Maximum output current: 15MA (VCC=5V, V-PP greater than 50%), 35MA (VCC=12V, V-PP greater than 50%) Output LED indicator (low level, LED is on, high level, LED is off; LED flashes with frequency The output frequency is continuously adjustable using the onboard jumpers and potentiometers. Jumper settings are: 1Hz ~ 50Hz 50Hz ~ 1kHz 1KHz ~ 10kHz 10kHz ~ 200kHz The output duty cycle can fine-tuned using the onboard potentiometers. Duty cycle and frequency are not separately adjustable; adjusting the duty cycle will change the frequency The output frequency and duty cycle are adjusted using the following variables: Period T = 0.7 (RA +2 RB) C RA, RB are 0-10K Ohm adjustable potentiometers 1Hz ~ 50Hz: C = 0.001UF 50Hz ~ 1kHz: C = 0.1UF 1KHz ~ 10kHz: C = 1UF 10kHz ~ 200kHz: C = 100UF Applications: As a square wave signal generator for experimental development Used to drive a stepper motor for generating a square wave drive signal Generate adjustable pulses for microcontrollers (MCU) Package Includes: 1X NE555 Duty Cycle Adjustable Pulse Frequency Square Wave Signal Generator Module Printed schematic, installation and operation instructions Ships from US stock in 1 business day for quick delivery. Don't wait weeks to get it from China. Buy it from the US today! Best Offers are considered for multiple piece orders only. Expand your DIY and Arduino-compatible development with these other Arduino-compatible development boards, shields and modules from Envistia Mall. We provide FREE USPS First Class Shipping with Tracking - Not Economy Shipping
