Ne555 Pulse Frequency Adjustable Module Square/square Wave Signal Generator

US $3600

Shenzhen, China
Nov 15th

Open on mobile:
QR code

Click to Enlarge Click to Enlarge Click to Enlarge Description NE555 pulse frequency adjustable module Square/square wave signal generator Specification: 1. use as a square-wave signal generator, generate square wave signals used for experimental development. 2. to generate square wave signal driving stepping motor drive. 3. adjustable pulses generated for use by the MCU. 4. adjustable pulse control related circuits. Description: size: 2.9CM*3.6CM 1, Main chip: NE555; 2, Input voltage: 5V-15VDC. (When 5V power supply, output current =15MA; when 12V power supply, output current=35MA); 3, Input current: ? 100MA 4, the output amplitude: 4.2V V-PP to 11.4V V-PP. (according to the different input voltage, output will be different) 5, Maximum output current: ? 15MA (5V power supply, when V-PP is greater than 50%), ? 35MA (12V power supply, when V-PP is greater than 50%) Characteristics and advantages: 1, output with LED indication(low level LED ON, high level LED OFF, at lower frequencies than the LED flashing); 2, the output frequency range level can be selected, the output frequency adjustable; Low frequency: 1Hz~50Hz MF: 50Hz~1kHz HF: 1KHz~10kHz HF: 10kHz~200kHz 3, the output duty cycle can Adjustable(Small), adjustable duty ratio will change the frequency. 4, the output frequency adjustable; Cycle T=0.7 (RA+2RB) c RA, RB for the 0-10K adjustable; C=0.001UF low frequency gear; C=0.1UF MF gear; High frequency in document C=1UF; C=100UF high frequency gear, wave frequency buyers can own calculation. Package Including NE555 pulse frequency adjustable module x 1 Recommended Products Check out my other items! Payment We accept Paypal only, It is fast, Easy and Safe. Payment must be completed within 7 days. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. Please list your special requests (color, packages, etc.) in the PAYPAL NOTES SECTION when you make payment. Shipping We Ship to Worldwide. Orders processed within 24-48 hours of payment verification. We only ship to confirmed PAYPAL addresses. Your PAYPAL address MUST MATCH your Shipping address. Package to USA will Shipping by E-Package with Tracking Number(7-15 Days to Delivered). To other Countries will shipping by Post Air Mail without tracking number(ONLY when the order is over 20USD will supply Tracking Number Shipping Way!)(15-35 Days to Delivered). Items are shipped via China Post & Hong Kong Post & Singapore Post Air Mail. Country Shipping Way Shipping Time Tracking Number United States EUB 7-12 Yes Other Country China/Hong Kong/Singapore Post Air Mail 15-35 No If you need tracking number. Please add 2.5usd Register Shipping fee. Warranty and Guarantee Good Good quality. Buy with confidence! If you are not satisfied when you receive your item, please return it within 7 days for a replacement or money back. Please contact me before you return it. Not accept returning of electronic components. Full refund after we receive our original item, Note: Return shipping is to be paid by the Buyer. We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Contact Us We strive to provide you with the best service, We will reply your question within 24 hours. Our goal is customer satisfaction! Our Working-time From 8:30 AM to 21:30 PM. you can check our working time from the World-time table. inkfrog terapeak
