NEW 50PCS Mini board WS2812B WS2811 IC (10mm * 3mm) DC 5V SMD 5050 RGB Led light Products: PIN function NO. Symbol Function description 1 VDD Power supply LED 2 DOUT Control data signal output 3 VSS Ground 4 DIN Control data signal input Absolute Maximum Ratings Prameter Symbol Ratings Unit Power supply voltage VDD +3.5~+5.3 V Input voltage VI -0.5~VDD+0.5 V Operation junction temperature Topt -25~+80 Storage temperature range Tstg -40~+105 Electrical Characteristics(TA=-20~+70,VDD=4.5~5.5V,VSS=0V,unless otherwise specified) Prameter Smybol conditions Min Tpy Max Unit Input current II VI=VDD/VSS —— —— ±1 µA Input voltage level VIH DIN,SET 0.7VDD —— —— V VIL DIN,SET —— —— 0.3 VDD V Hysteresis voltage VH DIN,SET —— 0.35 —— V Switching characteristics(TA=-20~+70,VDD=4.5~5.5V,VSS=0V,unless otherwise specified) Prameter Symbol Condition Min Tpy Max Unit Transmission delay time tPLZ CL=15pF,DIN-> DOUT,RL=10K? —— —— 300 ns Fall time tTHZ CL=300pF,OUTR/OUTG/OUTB —— —— 120 µs Input capcity CI —— —— —— 15 pF RGB IC characteristic parameter Emitting color Model Wavelength(nm) Luminous intensity(mcd) Voltage(V) Red 13CBAUP 620-625 390-420 2.0-2.2 Green 13CGAUP 522-525 660-720 3.0-3.4 Blue 10R1MUX 465-467 180-200 3.0-3.4 Data transfer time( TH+TL=1.25µs±600ns) T0H 0 code ,high voltage time 0.4us ±150ns T1H 1 code ,high voltage time 0.8us ±150ns T0L 0 code , low voltage time 0.85us ±150ns T1L 1 code ,low voltage time 0.45us ±150ns RES low voltage time Above 50µs I.Features and Benefits l Intelligent reverse connect protection, the power supply reverse connection does not damage the IC. l The control circuit and the LED share the only power source. l Control circuit and RGB chip are integrated in a package of 5050 components, form a complete control of pixel point. l Built-in signal reshaping circuit, after wave reshaping to the next driver, ensure wave-form distortion not accumulate. l Built-in electric reset circuit and power lost reset circuit. l Each pixel of the three primary color can achieve 256 brightness display, completed 16777216 color full color display, and scan frequency not less than 400Hz/s. l Cascading port transmission signal by single line. l Any two point the distance more than 5m transmission signal without any increase circuit. l When the refresh rate is 30fps, cascade number are not less than1024 points. l Send data at speeds of 800Kbps. l The color of the light were highly consistent, cost-effective.. II.Applications l Full-color module, Full color soft lights a lamp strip. l LED decorative lighting, Indoor/outdoor LED video irregular screen. III.General description WS2812B is a intelligent control LED light source that the control circuit and RGB chip are integrated in a package of 5050 components. It internal include intelligent digital port data latch and signal reshaping amplification drive circuit. Also include a precision internal oscillator and a 12V voltage programmable constant curre-nt control part, effectively ensuring the pixel point light color height consistent. The data transfer protocol use single NZR communication mode. After the pixel power-on reset, the DIN port receive data from controller, the first pixel collect initial 24bit data then sent to the internal data latch, the other data which reshaping by the internal signal reshaping amplification circuit sent to the next cascade pixel through the DO port. After transmission for each pixel,the signal to reduce 24bit. pixel adopt auto resha-ping transmit technology, making the pixel cascade number is not limited the signal transmission, only depend on the speed of signal transmission. LED with low driving voltage, environmental protection and energy saving, high brightness, scattering angle is large, good consistency, low power, long life and other advantages. The control chip integrated in LED above becoming more simple circuit, small volume, convenient installation. Package include: 50pcs X WS2812B 5050 leds Shipping Detail Delivery to US: USPS First Class Airmail 7-12 Work days Tracking number available Delivery to Others: HK Post Airmail 11-25 Work Days Tracking number available If you do not receive your winning item (s) by 35 business days,Please feel free to contact us through ebay mail system or E-mail, we will try our very best to resolve any problems with you. Payment Method We accept only PayPal payment. A non-payment dispute will be opened if full payment is not received after 14 days of auction. inkfrog terapeak i000000
