New Boc Edwards Sipv25pka Soft-start Nw25 Vacuum Valve, Asm Pn: 50-123931a01

US $150

Phoenix, Arizona, United States
Jun 20th

Open on mobile:
QR code

NEW BOC Edwards SIPV25PKA Soft-Start NW25 Vacuum Valve, ASM PN: 50-123931A01 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from BOC Edwards and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is new, old stock from excess ASM inventory. The ASM Tag Reads: Part Number: 50-123931A01 Description: VALVE-PNEU-SOFT START NW25 The Serial Number Tag Reads: Model Number: SIPV25PKA Part Number: C41624000 Serial Number: 027255088 Switch: 24 V, 0.25 A Max. Pressure: 7 Bar Link to the Manual: BOC Edwards SIPVP-Series Soft-Start Valve Manual Features and Benefits: MTTF of 5,000,000 cycles Controlled pump down to match process Aluminum bodies Fast acting valves in the event of power failure Supplied with 5 mm, 6 mm and 7 mm interchangeable orifices Bellows sealed for clean operation Easy to service with replaceable orifices Bakeable to 100°C to prevent condensation of process gases Description: Soft-start, pneumatically operated, in-line valves with interchangeable orifices for the controlled pumpdown of processes where turbulent flow can cause problems with particulate contamination. Slave and master valve combination allows slow initial pumping to minimize disturbance. Both slave and master valves require separate pneumatic connections. Specifications: Valve Actuation Type: Single acting, pneumatically opened, spring closed Pressure Range: 1 x 10-9 to 2100 mbar (8 x 10-10 to 1575 Torr) Maximum Pressure Differential: Opening: 1000 mbar / 750 Torr Closing: 2100 mbar / 1575 Torr Leak Rate: 10-9 mbar ls-1 (10-10 Torr ls-1) Pneumatic Connector: Rp 1/8 (1/8 inch BSP)* Pneumatic Operating Pressure: 2.8 to 4.2 bar (41 to 61 psi) Electrical Indicator: Single microswitch Microswitch Electrical Rating: 24 V, 1.5 A - AC or DC Max. Cycle Frequency: 900 h-1 Bellows Reliability: 5,000,000 cycles Ambient Operating Temperature: 5 to 100°C Maximum Baking Temperature: 100°C Construction Materials: HE30TF aluminum O-Ring: Fluoroelastomer Time to Open/Close at 4 Bar: Slave Valve: 60 ms/20 ms Master Valve: 15 ms/41 ms Weight: 920 g (32 oz) For More Pictures Please Click the Following: Picture 2 - Side View #1 Picture 3 - Side View #2 Picture 4 - Side View #3 Picture 5 - Side View #4 Picture 6 - Serial Number Tag Picture 7 - ASM Part Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $0.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 01/04/13 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
