New Ca1641 Function Generator/counter 20% Off

US $232.00

Ontario, California, United States
Jan 29th

Open on mobile:
QR code

New CA1641 Function generator/counter - 20% Off! These amazing markdowns will not last forever. Originally $290, the CA1641 is now only $232. You won't find this unbeatable price anywhere else. Description CA1641 is a great basic generator. It is an improved version of the CA1640 with added modulation features. Reliable circuitry ensures high stability and accuracy. This instrument can produce signal generating functions such as dual_channel function, linear sweep frequency, logarithmic sweep frequency, FSK, AM, FM, any counts generation function for function signals, and more. It is an ideal device for electronic engineering, scientific research, labs, production lines, and teaching contexts. Main Features Large scale integrated circuits, high speed micro-processor technology adopted into the instrument for maximum efficiency performance With the functions sine wave, square wave, pulse wave, and triangle wave Internal linear and logarithm sweeping, FM, AM, FSK modulations; External FM, AM. Digital frequency display and frequency counter Sleek, artistic cabinet design Easy, safe, and comfortable key operation Frequency range: 0.2Hz-20 MHz Output signals: symmetrical or non-symmetrical sine, square and triangle waveforms. Symmetry is continuously adjustable. Outputs: 50 ?, TTL and power level. DC bias: -5V-+5V. LED readouts of frequency and voltage level. Built-in frequency counter: 0.2Hz-20 MHz. Internal or external frequency sweeping. Specifications Frequency range 0.2Hz~20Mhz Waveforms sine,square,triangle, pulsewaves Output impedance 50 ?hms Output voltage 1mVp-p~10Vp-p at 50 ? 1mVp-p~20Vp-p at 1M ? 50Vp-p, 1Ap-p, CA1640P-20 Output modes single frequency, sweeping Symmetric 20%~80% DC offset -5V~+5V TTL output "1" >+3V, "0" <0.8V TTL output impedance 600 ? TTL waveform pulse Frequency counter 0.2Hz~20Mhz Power 110V, 60Hz, 30W Size 265x215x90(mm) Working temperature 0~40C Average stability 0.5%, max fluctuation may reach 1.5% at some frequencies Function output levels 0dB, 1Vp-p~10Vp-p, 10% accuracy 20dB, 0.1Vp-p~1Vp-p, 10% accuracy 40dB, 10mVp-p~100mVp-p, 10% accuracy 60dB, 1mVp-p~10mVp-p, 10% Waveform distortions sine: <1% triangle linearity: >90% Square: <5% at 10kHz, 5Vp-p, rising time<17nS Front Panel Controls GATE Every flash indicates the completion of a measurement SYM output signal symmetry adjustment FREQUENCY frequency range SWEEP/COUNTER selection of function output, sweeping or counter mode FUNCTION SIGNAL OUTPUT output level selection WIDTH sweeping range adjustment RATE sweeping time adjustment WAVE selection of output waveforms AMPL output amplitude adjustment OFFSET output signal offset adjustment FILTER input low pass filter, used in frequency counter mode 20dB input attenuation, used in frequency mode ITEM IS IN STOCK. SAME DAY SHIPPING!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	CA1641
Manufacturer	Madell Technology Corporation
