New Cnc Standard 3axis Tb6560 Stepper Driver Full Kit & Motor/psu/keypad/display

US $226.99

  • HK, Hong Kong
  • Jun 9th
{{{TBR_DOMAIN_NAME}}} eBay Item New CNC Standard 3Axis TB6560 Stepper Driver Full Kit & Motor/PSU/Keypad/Display SAVEBASE is a customer satisfaction oriented online business company supplying you with the best valued and affordable accessories and parallel devices for your personal digital equipments.Enjoy peace of mind shopping experience with us. © SAVEBASE.com All Rights Reserved Only USD +P&P USD* More.. Product Info Jump to :: Specifications :: What's in the Box The Latest 3rd Generation Revolutionary & Standard TB6560 3 Axis Stepper Driver Set (TB3CD-S) + 3 x Nema17 0.54Nm/76 Oz-in 42BYGH47-401A Stepper Motors + 1 x 120W 12V10A Switching Power Supply I: PCB Instructions & Specifications Descriptions The latest 3rd generation TB6560 Stepper Driver has been upgraded to the intelligent, professional and industrial-level drive set by re-designing the PCB board, embedding intelligent memory chip(professional version) and upgrading the external manual control tools (control pad and display panel). Actually, the 3rd generation TB6560 Stepper Drivers have two types of versions, one is the standard version, and another is the professional version. Compare to the standard version, the professional version mainly has two more functions than the standard version, one is the “computer G-code recording function”, and another is the “manual programing function”. Except these two functions, these two types of versions have no other differences. Firstly, both of these two types of versions have upgraded their PCB boards, the re-designing the PCB board will avoid the TB6560 chip on the board being easily blown as the previous version. With the embedded intelligent memory chip, the professional version of this 3rd generation 3 Axis TB6560 Stepper Driver can easily record the G-code running on the CNC software (e.g. Mach3, EMC2, KCAM4, etc..) of the computer, and then rerun the recorded G-code to make the stepper motor work without the computer any more. Furthermore, the upgraded external manual control tools (display panel and control pad) on the professional version can be not only used for manually controlling the stepper motor, but also manually programming the G-code. All the manually Programmed G-code will also be recorded in to the embedded intelligent memory chip, and then we also can easily run the recorded G-code to control the stepper motor. Considering that the computer G-code recording function is enough for all the three axis working without computer, to avoid repeated function, the manual programming function is mainly designed for one axis to make linear motion, therefore, the three axis cannot be manually programmed simultaneously. This function is widely used on working which just need one Axis, such as RBI machine, Conveyor etc. Lately, both of these two types of versions adopt the totally enclosed optical isolation and bipolar constant-current chopper to insure working at low noise & vibration, and avoid creeping at a low speed. It is very suitable for driving the 2-phase and 4-phase hybrid stepping motors. In short, the qualities and functions of the new 3rd generation advanced 3 Axis TB6560 Stepper Driver are revolutionized from the previous version. So, we believe that these two types of versions must satisfy different users on CNC DIY. The item you are watching is the 3 Axis Standard Version (TB3CD-S) CNC kit with stepper motors and power supply , if you need the other versions, please feel free to contact with us. Features High performance, cost-effective. Automatic idle-current reduction. To manually control the stepper motor, both of the standard and professional drivers have been equipped with the display panel and control pad. Automatically identify both of the computer and control pad, functions of the computer and control pad can be switched intelligently for each other without any interference. Display panel can real-time trail the running path of G-Code on the computer or input by the control pad, and then completely and Simultaneous display the changing of each axis'(X, Y, Z axis etc.) values on its screen. Both of the standard version and professional version are compatible with the Mach2, Mach3( Default Software ) , LinuxCNC(EMC2), KCAM4 CNC Software, etc.. Besides, the professional version also can automatically trail the path running path of G-Code from the CNC software (e.g. Mach3, EMC2, KCAM4, etc.) of the computer and record the G-code into the memory chip; Easy to repeatedly run the G-code to control the stepper motors without computer. The professional version also support manual programming via the control pad, as long as input the required values on one axis and record them in the memory chip of the driver, and then run these recorded values to drive the axis to make linear motion, widely used on RBI machine, Conveyor and so on. Automatically finish Tool-settings on X, Y, Z Axis via the control pad, without the support of the computer. Compatible with all the motors with 0.5A-3.5A (peak) rated current, four types of adjustable output current can be set on the driver board. 1, 2, 8, 16 adjustable microstep control, motors run more precisely and smoothly. Overload, overcurrent, overvoltage, overheat protection to avoid damaging your computer and devices. Totally enclosed optical isolation and bipolar constant-current chopper to insure motors work at low noise & vibration, and avoid motors creep at a low speed. With one 0-10V PWM Signal output port for speed adjustment and one Relay control port. 5 types of input control in manual control interface, to set Limit, Estop, Midpoint-Setting, Cutter-presetting/Tool-Setting etc... Applications For processing various pattern mould. For advising, such as brand, architechture mould, badge, nameplate, display boards, doorplate, furniture decoration, etc.. For carving portrait, scenery, handwriting, sealing, etc.. Suitable for any small-and-medium automatic equipment with CNC controller, such as X-Y-Z tables, labeling machines, laser cutters, engraving machines, and pick-place devices. Dip Switch Settings II: DIP Switch Settings Output Current Selection Output Current SW1 SW2 100% ON ON 75% ON OFF 50% OFF ON 25% OFF OFF Decay Mode (Buffer) Selection Decay Mode (Buffer) SW3 SW4 25% ON ON 50% ON OFF 75% OFF ON 100% OFF OFF Microstep Resolution Selection Microstep Resolution SW1 SW2 1 ON ON 2 ON OFF 8 OFF OFF 16 OFF ON Note: If the drive board has abnormal noise under working or locking condition, you can solve the problem by adjusting the decay mode. Further Details DC 12-32V power supply selection Voltage Selection : 12-16V DC power supply for Nema 17 stepper motors 16-24V DC power supply for Nema 23 stepper motors 24-32V DC power supply for Nema 34 stepper motors ( High voltage will burn out the chips or stepper motors!!!) Current Selection: Output current of the power supply can be calculated by the following formula: Output current = Rated current of your stepper motors * quantity + 2A (For example, if you want to drive 3 * 2A Nema 23 stepper motors, theoretically 24V 8A DC power supply is recommended, but higher power such as 24V 10A/15A also will be good.If you are not sure about the selection of power supply, please feel free to contact us for help) Please SHUT DOWN the power before you plug or unplug the connectors to avoid burning up the board Connection Diagram For Reference III: Connection Diagram Specifications Electrical Specifications Of Stepper Driver Input voltage 12V-32V DC Output current 0.5A-3.5A (Peak) Drive type Pulse + Direction + Enable Signal Control (Bipolar constant-current PWM output) Suitable motor Nema17, Nema23, Nema24, Nema34 (Rated current: 0.5A-3.5A) Net weight 305g (Driver) Dimensions 173 x 113 x 38mm Operationg Environment & Other Specifications Of Stepper Driver Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0°C-50°C (32°F-122°F) Humidity 40%RH-90%RH Operating Temperature 70°C (158°F) Max Storage Temperature -20°C-65°C (-4°F-149°F) Total Weight Approx. 535g (Driver + Control Pad + Display Panel) Specifications Of Power Supply Input voltage 100-240V AC Input frequency 47/63hZ Output voltage 12V Total current 10A Vout adjustable range 12V±10% Size 199 x 99 x 42mm Weight 600g Specifications Of Stepper Motor Model 42BYGH47-401A Shaft Single Shaft (Diameter:5mm; Length:21mm) Rated voltage 2.8VDC Rated current 1.68A/Phase Step angle 1.8°±5% Phase 2 Phases Phase resistance 1.65x(1+10%)?/Phase Phase inductance 2.8x(1+20%)mH/Phase Holding torque 0.54Nm (Approx. 76 Oz-in) Positioning torque 150gf.cm Insulation resistance >=100M? (500VDC) Insulation class Class B Weight 0.35Kg/Piece What's In 1 x The 3rd Generation 3 Axis TB6560 Stepper Driver (Standard Version) 1 x External Control Pad (Standard Version) 1 x External Display Panel (Universal) 3 x 42BYGH47-401A Stepper Motors 1 x 12V10A Power Supply 1 x LPT Parallel Cable 1 x CD Click here for the detailed schematic diagram of the stepper motor Click here for the Mach3 software We sell items to most countries of the world. For cost saving purpose, we can't keep a lot of stock for every item in every location. Your order with us may be sent from anyone of our dispatch centers that has sufficient in stock quantity. There is no extra charge for such a delivery service. Typical delivery durations(for reference only) are: Estimated Delivery Time (Airmail Packets) UK, Australia, New Zealand, South Asia, East Asia 10-15 business days USA, Canada, other EU countries(France,Germany, etc.) 10-18 business days Italy, Spain 20-30 business days South America, Other Countries 15-20 business days Please DO CONTACT and confirm with us before you bid IF you: - need the item urgently. - require that the item should be shipped from a specific city. - require that the item to be delivered within a certain period. - have any other questions/requirements about delivery. Remarks: *Your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notifications will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *Most parcels will be shipped by Airmail packets, it is not guaranteed that parcel should arrive within the time stated above.However, 95% parcels will be delivered within the reference time. *It is not possible to track airmail parcels' locations over the internet. We will help you to track orders if there are problems with them. *You will get the combine shipment discount automatically when checking out. If you have any problem in getting that discount please contact us. * PayPal: We accept PayPal ONLY (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) Remarks: *Please send payment within 5 days after auction ended. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure your shipping address is correct. 30 Days Money Back Guarantee: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. Free Replacement: If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: We offer one year warranty on all products purchased from us. If your item has any warranty issue please contact us for a satisfying solution. Remarks: *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are not refundable. Agreement: By placing an order, you acknowledge that you have accepted the terms and conditions of sale.You are welcome to contact us with any questions.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand HY
UPC 190080036751
MPN 100367501
