New Controller, Regen, Motor, Dc, 0.5 Hp, Scr Half Wave Minarik Corp. Rg51ua

US $180.00

Chicago, Illinois, United States
Mar 2nd

Open on mobile:
QR code

YOU ARE VIEWING A MINARIK CORP. MOTOR CONTROLLER INPUT 115VAC ,1 PH. 6A. ARMATURE 0-90VDC , 1A. INCLUDES ALUMINUM CHASIS. USER MANUAL @ resources.minarik.com/resources/minarik-drives/manuals/RG51UA.pdf Regenerative drives, like Minarik’s RG51UA, control brush-type DC motors for applications that require bi-directional variable speed and smooth motoring or braking torque in either direction of rotation. The RG51UA is ideal for OEMs: These half-wave SCR drives deliver 1/2 HP. The compact size and low-cost distinguish them from other regenerative drives on the market. Applications with overhauling loads, rapid deceleration, basic positioning, reversing and braking benefit from these versatile regenerative drives. These drives are ideal for low duty cycle applications. FEATURES & BENEFITS 4Q Reversing: Regenerative / 4 quadrant drives have the ability to perform quick, contactorless reversing on-the-fly! Speed Range And Regulation: 3% regulation over 50:1 speed range. User Adjustable Calibration Pots: IR compensation, max speed, forward torque, reverse torque and deadband. Stopping Modes: Regenerative braking (N.O.). Screw Terminal Block: Easy to terminate wires. APPLICATIONS Conveyors Textile Machinery Printing Machinery Packaging Machinery Door Openers SPECIFICATIONS: Type: DC Drive - SCR Half Wave Regen DC Drive Input Voltage: 115V Output Voltage: 75V Horsepower: 0.5 HP Enclosure: Open Chassis Braking: Yes Reversing: Yes Programmable: No Max Armature Current (Amps DC): 5.0 HP Range With 115 VAC Applied: 1/8 – 1/2 Field Voltage (F1 to F2): 100 VDC Maximum Field Current: 1 ADC AC Line Voltage: 115 VAC, ±10%, 50/60 Hz, Single Phase Peak Current Limit: 9 ADC MaximumArmature Voltage Range at 115 VAC Input: 60–75 VDC Form Factor: 1.77 at Base Speed Acceleration Time (With Load): 1 Second Deceleration Time (With Load): 1 Second Speed Adjust Potentiometer: 50K? (Not Included in Lot) Analog Input Voltage Range (Isolated; S1 to S2): 0–10 VDC Input Impedance (S0 to S2): 100K? Load Regulation at Base Speed: 3% SpeedRange: 50:1 Weight: .75 lb (340 grams) Ambient TemperatureRange: 10°C–55°C Vibration: 0.5g max (0 – 50 Hz) 0.1g max (above 50 Hz)

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	MINARIK CORPORATION
MPN	RG51UA
Model	RG51UA
Country/Region of Manufacture	United States
