New!! Dart Speed Pickup Pu-20e Pulsegenerator,10 Pulse/rev,4.5 To 24vdc, Indoor

US $91.20

Griffith, Indiana, United States
Jan 29th

Open on mobile:
QR code

NEW!! Qty-1-In stock at time of original listing, Dart Controls PU series speed pickup, PU-20E, PU20E, speed pick-up, tach pick-up, The PU Series pick-up is an economical and reliable way to monitor motor speed. Its unique design provides ease of installation in otherwise difficult to reach areas. The PU pick-up operates at a 5 to 24 volt level producing a sharp square wave output, which may be fed into Dart’s field programmable tachometer, closed-loop control, counter, or any other digital device. The PU pick-up series also includes a quadrature model to monitor both motor speed and direction by providing two square wave output signals 81° out-of-phase, For more information call Mike Burvan @ 219-922-2668, burv@jorsm.com or visit www.midwestpowerproducts.com Manual: http://www.dartcontrols.com/wp-content/uploads/2012/05/1423J.pdf Description Our stock #PU20E HP: N/A Output RPM: N/A Ratio: N/A Voltage input: N/A Phase: 1 Hertz: 60 or 50 Frame: N/A Mounting: field Enclosure: Nema 1 Manufacturer: Dart Controls, Dart Electric Notes: New in box!! DART CONTROLS PU-20E PulseGenerator,10 Pulse/Rev,4.5 to 24vdc PDF Downloads: PU QUAD Manual | PU-R Specifications 3D View / Drawings The PU Series pick-up is an economical and reliable way to monitor motor speed. Its unique design provides ease of installation in otherwise difficult to reach areas. The PU pick-up operates at a 5 to 24 volt level producing a sharp square wave output, which may be fed into Dart’s field programmable tachometer, closed-loop control, counter, or any other digital device. The PU pick-up series also includes a quadrature model to monitor both motor speed and direction by providing two square wave output signals 81° out-of-phase. There are two versions of the product: The PU-E is rated for indoor industrial applications. The NEW PU-R is rated NEMA 4/4X for outdoor applications where temperature, humidity, rain and dust are present. The PU-R is also recommended for applications where water washdown is expected. Completely self contained, the PU Series eliminates the alignment hassle found with other devices. Encapsulated sensor head is dust and dirt resistant. An excellent ‘Motor Not Running’ feedback device to plc/SCADA systems. MODEL NUMBER (INDOOR) MODEL NUMBER (OUTDOOR) OUTPUT PU-2E PU-2R 1 Pulse/rev (PPR) PU-4E PU-4R 2 PPR PU-20E PU-20R 10 PPR PU-20E QUAD* PU-20R QUAD (future) 10 PPR AND DIRECTION PU-40E PU-40R 20 PPR Specifications

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Dart
MPN	PU20E
Model	PU-20E
Country/Region of Manufacture	United States
