New Digital Portable Palm OTDR Meter Tester RY-OT4000 32/30dB 1310nm/1550nm Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge a) Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. b) Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. Note: the price here is only for RY-OT4000. By default, we will ship the product with voltage and frequency standard in the recipient's country. If you need something different, please send us a message. Overview RUIYAN OTDR-4000 series portable optical time domain reflectometry (OTDR) is the latest FTTx optical fiber cable-based test instrument. It has light weight, elegant appearance, small size, easiness of installation and maintenance, high-capacity built-in battery. It provides multiple built-in test wavelengths and optical testing functions like visual fault locator (VFL). As a new product specially designed for FFTx network testing, it provides site technicians with the highest performance and upgrade services. Features Advanced anti-reflective LCD, display interface is clearly visible in bright light (VFL)Visual fault location function It provides high-speed USB port, waveform file conversion and printing convenience Long-lasting lithium battery, ideal for long-time outdoor construction work Online upgrade function, users do not have to go back to original factory to upgrade the system. Main functions 1. Fast automatic test Automatic test function allows the user not to have to know more details about the equipment operation, test steps become very simple. User only needs to connect in the optical fiber, click Test button, then the instrument will automatically set optimal test conditions and eventually give accurate test results, such as the test curve and event lists. 2. Fast curve analysis It can find out the event point or failure point in test curve and its location information quickly and accurately test curve, and list all event information in the circuit in the form of event list. This is very helpful for circuit maintenance personnel, not only improves the testing efficiency, but also eliminates the need to learn difficult background knowledge. 3. Powerful document management In addition to the ability to store, view, delete the files in the machine, it also provides PCL language-based laser or jet printers to print test reports. Besides, it also utilizes PC software to realize high-speed communications with PC via USB cable. 4. Convenient VFL function With visual IR VFL function, it can easily and quickly the locations of disconnecting points or big loss points in short-distance optical fibre links, so that the maintenance personnel could take measures in shortest time therefore saving a lot of time. 5. Manual test mode Users can choose real-time test mode or average test mode according to the testing needs. Real-time test can fast test the dynamic change of optical-fibre links. It is mainly used for the connecting occasions requiring monitoring or observing optical-fibre links at real time. 6. Average test mode Average test mode is used to withhold the noise in test curves to the most extent, therefore obtain more accurate testing results. In average test mode, the number of averaging tines will influence the effects of suppressing the noise in test curves. The bigger the number of time is, the effect the time is, but the testing time is to be extended accordingly. Therefore, user should set averaging time based on actual need. 7. Dead zone test mode It is suitable for the test of ultra short-distance optical fibre. Specifications Model RY-OT2000 RY-OT1000 RY-OT4000 RY-OT5000 wavelength 1310nm/1550nm 850nm/1300nm 1310nm/1550nm 1310nm/1550nm/1490nm Fiber Type Single-Mode Single-Mode Single-Mode Single-Mode Dynamic Range 15/16dB 22/23dB 32/30dB 36/35dB Measurement range (single ) 50-60KM 80-100KM 140-160KM Event dead zone 0.8m/0.1-16m Accuracy +(1m+ Sampling interval +0.003%*Distance) (excluding refractive index imbedding error) Resolution 0.1m-16m Loss Threshold 0.01dB Linearity 0.05dB/dB VFL output power 5mW Measurement range (single ) 1.6km-80km Pulse width (single mode) 10ns~1024ns Number of sampling points 65K Waveform storage capacity 1000 frames Range of refractive index 1.00000~2.00000 Range of optical-cable correction factor 0.80000~1.0000 Display Color TFT LCD, 5.1 inch, 640*480 Port USB Optical output port FC/PC Power supply AC/DC adapter: AC input: 100V~240V(1.5A) Output DC: 9V(2A) Power frequency: 50Hz~60Hz Internal lithium battery: 7.4V, 3200mAh Working hours of battery: 10 hours (normal temperature) Menu language Simplified Chinese/English Environmental requirements Storage temperature: -40°C~70°C(exclusive of battery) Relative humidity 5%-95%, no condensation Dimensions 215mm*130mm*66mm Weight About 1kg Necessary Attention in behind: 1. Most of our items have 1 year warranty. 2. All the products we sell are brand new. All products have been checked and packaged in good condition before dispatch. 3. If item arrives faulty, please contact us first and send it back, we provide replacement or full refund to buyers 1. Customer Satisfaction is always our Top Priority. 2. We are always here to provide help. If you are not satisfied with our products or services, before you leave neutral or negative feedback, or open dispute, please contact our customer service first. We are sure that we can find out a solution to keep buyer satisfied. 3. Emails and messages are answered within 24 hours, Monday to Friday except public holidays, if you don't receive our reply exceed 48 hours, please send it again,maybe we don't receive your letter. 1. For all cases, shipping fee is not refundable and buyer is responsible for the return shipping cost. 2. If you encounter any problems about anything, please feel free to send us inquiry and we will do our best to assist you solve the issue. If you feel any dissatisfaction, please also feel free to let us know to give us a second chance. 3. The custom duty and import cost are the responsibility of buyer,pls check with your local customs some related tariffs policy before you make an order. Thanks for your kindly understanding! 1.We will send out the item within 1-2 business days after the payment is received.All items sold are new before sent out. 2.Item will be sent out by airmail (Such as: China Post,Hongkong Post,Singapore Post Etc.).Normally delivery time is within 15-20 working days in normal countries. We hope it arrive on time but since this is an international delivery, shipping time will be highly depended on the courier company and local customs/duties. 3.We will send item to your Confirmed Shipping Address in PayPal. If you would like to post to other address , please timely leave us a note when making payment through PayPal. 4.If your delivery address is remote area, you need to pay more $30-$50 remote shipping cost. 1.We only accept paypal . 2. Please make payment within 7 days after auction ended, if not,we have to open an unpaid cace to get our final value fee back from ebay.So please contact us timely before we take this action.Thanks! 3.We don't responsible for any custom duty or import cost. 4. Please tell us the value/name of the item you want for custom delaration if you have any special requirement,or we will fill the custom declaration which is suitable for most countries accordingly. inkfrog terapeak i000000
