New Eimac Y-540/y540/ml-ee64y/y482/7211/8755 Tube

US $499.99

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! NEW Eimac Y-540 Tube Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Richardson Electronics and may vary slightly due to upgrades, options, or revisions this unit may or may not have. New in the factory box. The Y-540 is a replacement for the Y-482/7211. It has a special gird and mount. 8755 Cap: No Radiator. Used in Ham Radio, Induction Heaters, Plasma Generators, and RF Generators. Description: The Y-540 is a rugged planar triode designed for switch tube or pulsed regulator service in advanced groun, airborne, or space applications. Design features include an arc-resistant cathode to assure stable and reliable long-life operation under adverse conditions. An added feature is the increased grid-to-cathode insulator length to permit operation at high plate voltages and/or higher altitudes. The Y-540 is normally supplied without a radiator and may be conduction, convection, heat-sink, or liquid cooled, as immersion cooling in an insulating medium (e.g., FC-75). The tube has solder tabs on the cathode, heater, and grid terminals. Specifications: Amplification Factor (µ): 75.0 (145 Mu) Cathode: Oxide-coated Unipotential Anode Current (A) Maximum: 5.0 Anode Dissipation (W) Maximum: 150 Anode Voltage (kV) Maximum: 8 Grid Dissipation (max.): 1.5 watts Plate Dissipation (max.): Depends on cooling technique Anode: Threaded stud, 5/16-24 UNF-2A for heat transfer and electrical contact. Brand: Eimac Duty Cycle @ MO PW: 0.0033 @ 1.0 Filament Current (mA): 1,300 Filament Voltage (V): 6.300 Transconductance (µmhos): 30 Typical Anode Current (mA): 5,000 Typical Anode Voltage (V): 2,500 Typical Power Out (W): 3,000 Capacitances: Grid-Cathode: 9.0 pF Grid-Plate: 1.4 pF Plate-Cathode: 0.06 pF Maximum Length: 1.56 in (39.60 mm) Maximum Diameter: 0.78 in (19.90 mm) Operating Position: Any For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 3/3/04 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
