New Electret Microphone Amplifier MAX4466 with Adjustable Gain for Arduino Description: Add an ear to your project with this well-designed electret microphone amplifier. This fully assembled and tested board comes with a 20-20KHz electret microphone soldered on. For the amplification, we use the Maxim MAX4466, an op-amp specifically designed for this delicate task! The amplifier has excellent power supply noise rejection, so this amplifier sounds really good and isn't nearly as noisy or scratchy as other mic amp breakouts we've tried! This breakout is best used for projects such as voice changers, audio recording/sampling, and audio-reactive projects that use FFT. On the back, we include a small trimmer pot to adjust the gain. You can set the gain from 25x to 125x. That's down to be about 200mVpp (for normal speaking volume about 6" away) which is good for attaching to something that expects 'line level' input without clipping, or up to about 1Vpp, ideal for reading from a microcontroller ADC. The output is rail-to-rail so if the sounds gets loud, the output can go up to 5Vpp! Using it is simple: connect GND to ground, VCC to 2.4-5VDC. For the best performance, use the "quietest" supply available (on an Arduino, this would be the 3.3V supply). The audio waveform will come out of the OUT pin. The output will have a DC bias of VCC/2 so when its perfectly quiet, the voltage will be a steady VCC/2 volts (it is DC coupled). If the audio equipment you're using requires AC coupled audio, place a 100uF capacitor between the output pin and the input of your device. If you're connecting to an audio amplifier that has differential inputs or includes decoupling capacitors, the 100uF cap is not required. The output pin is not designed to drive speakers or anything but the smallest in-ear headphones - you'll need an audio amplifier (such as 3.7W stereo amp) if you want to connect the amp directly to speakers. If you're connecting to a microcontroller pin, you don't need an amplifier or decoupling capacitor - connect the OUT pin directly to the microcontroller ADC pin. For audio-reactive projects, we suggest using an FFT driver library which can take the audio input and 'translate' it into frequencies. Package Included: 1 X Electret Microphone Amplifier MAX4466 with Adjustable Gain for Arduino Shipping Feedback Payment Return/Refund We will ship to worldwide by 1) Standard Economy Airmail , or 2) Registered Airmail with Tracking. It takes approximately 18 to 35 working days for delivery (business days – excluding holidays), kindly be patient. If you do not receive your delivery within the specified time frame, please contact us via eBay message for assistance. Kindly ensure that your delivery address in eBay & Paypal are the same to avoid delivery failure. Any non-received item caused by invalid address is not eligible for refund or replacement. Please ensure your purchased item(s) can be lawfully imported into and complies with all laws and regulations of the destination country. IMPORTANT NOTE: Custom duty is obligation and liability. Buyers are responsible for import duties, custom fees and taxes, if any. Kindly check with your country’s custom office to determine the additional costs impose on the item prior to purchase. We are NOT responsible for the additional costs incurred related to import duties, custom fees and taxes. Please leave a note in eBay ONLY if you got special request (e.g. colour). Kindly note that special request is subject to availability; we does NOT guarantee for random ship items. We will greatly appreciate your positive feedback and all 5-star DSRs. If we have not given you reason enough for 5-star grades on each DSR, please let us know how we can earn your 5 star rating before submitting your scores. We accept PayPal payment only, and must be received within 3 days from the date of purchase. Please leave note in PayPal when making the payment if you have any special requests. Orders will be processed instantly and dispatched within 1-2 days, so we do NOT accept any email/message note after you place orders. IMPORTANT! PLEASE READ! Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country Kindly examine your parcel upon receiving your purchase and inform us via eBay message of any damage/defects with clear photographs/pictures/videos as proof within the first 24 hours upon receiving your purchase. NO claims will be liable or entertain after this time period. If you are not happy with your purchase for valid reason, you can return the product to us within the first 14 days after receiving the product. All shipping charges (both ways), handling and packaging costs will be charged to the buyer. The product must be sent back to us in original condition with no defect (new, unused and unopened) within first 14 days of receiving the product. No scratches, damages whatsoever & No altering of any part of the item. Original box/documentation/accessories (if any) and packaging. Buyer is responsible for return shipping cost. Please allow up to 5 working days to process your return items. On Oct-26-16 at 10:42:19 PDT, seller added the following information:
