New Pcf8591 Module Ad Da Conversion Module Mcu Conversion Module Robot

US $7.99

??, ???, China
Feb 23rd

Open on mobile:
QR code

New Pcf8591 module ad da conversion module mcu conversion module robot PCF8591 is a monolithic, single supply, low power, 8-bit CMOS data acquisition device. The PCF8591 has four analog inputs, one analog output and a serial I2C bus interface. PCF8591 the three address pins A0, A1 and A2 can be 2 for programming the hardware address, allowing access to the same I2C bus - PCF8591 8 devices without the need for additional hardware. The PCF8591 device on the input and output address, control and data signals are bi - directional two - wire I2C bus for transmission in a serial manner. PCF8591 key performance indicators: Single power supply PCF8591 operating voltage range of 2.5 V to 6 V Low Standby Current Via the I2C bus - serial input/output PCF8591 through 3 hardware address pins addressing PCF8591 I2C bus speed from rate decision 4 analog inputs programmable as single - ended or differential inputs Auto increment channel selection PCF8591 analog voltage range from VSS to VDD PCF8591 built - in track and hold circuit 8-bit successive approximation A/ D converter Through an analog to the output of the DAC gain Two baby description: A module chip PCF8951 4 - channel 2 module supports an external voltage input capture (voltage input range 0 to 5 v) 3 the module integration photoresistor, you can capture the ambient light intensity through the AD precise values 4 the module integrated thermistor temperature by exact numerical AD acquisition 5 the module integrates a channel 0 to 5 v voltage input capture (via the blue potentiometer adjustment input voltage) 6 the module with power indicator (the module after the power indicator towns) 7 the module with DA output indicator, the when the module DA output interface voltage reaches a certain value, the board will be lit DA output indicator, the who the voltage, the light intensity is more obvious; 8 the Module PCB size: 3.6 cm * 2.3 cm 9 standard double panel, thickness of 1.6 mm, nice layout, surrounded by a through hole, aperture: 3 mm, work fixed Three module interface description: This module expansion outside the left and right, respectively, two - way pin headers, respectively, as follows: DA output interface chip left produce AOUT AINO chip analog inputs 0 AIN1 chip analog inputs 2 AIN2 chip analog inputs AIN3 chip analog input interface. 3 Right SCL IIC clock interface connected microcontroller IO port SDA IIC digital interface connected microcontroller IO port GND Module to external ground VCC Power Interface External 3.3 v to 5 v Four modules use red short cap There are three red module shorted cap, respectively the function as follows: Connect the shorting cap P4 P4, select thermistor access circuit Connect the shorting cap P5 P5, select photoresistor access circuit Connect the shorting cap P6 P6, select 0 to 5 v Adjustable voltage access circuit Payment Policy: We ONLY accepted PayPal payment. We will ship to the shown address on you PAYPAL Payment notice, Please confirm your shipping address in the PayPal Account. If you don't have Paypal account, please sign up and learn more about paypal at: www.paypal.com. Payment must be fulfilled within 7 days since auction's ending. shipping & time: Generally, delivery time is 10-20 business days to USA, United Kingdom, Australia and 15-30 days to most other countries. Items will be shipped within 1 business day on payment received. Delivery time depends on destination and other factors, it may takes up to 30 business days. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Returns Policy: All sales come with us 14-day warranty. Return items must not be used or have any sign of abuse or intentional damage. Buyer is responsible for all return shipping charges. We reserve the right not to refund S&H when the item has been posted. Contact us: If you have any questions,Please contact with us via eBay message or our customer service e-mail. please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 11:00 - 20:00 and Saturdays 11:00 - 15:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) Feedback: Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us a positive feedback . When you rate the shipping time part please take international transit into consideration. Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and pleasant shopping with us. Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. thank you !
