New pulse generator 1Hz ~ 100KHz PWM module servo signal duty cycle of 1~99% Description: HM200 is a small signal generator, can produce maximum 100KHz frequency and duty cycle variable pulse signal, can also generate servo control signals. The module is easy to use, through the key operation, input frequency data, update the output frequency. Application: Signal generator; Instrument calibration; DC motor control; Technical Data Sheet: Pulse signal range: 1 ~ 100000 Hz, duty cycle of the pulse signal from 1 to 99% Pulse duty cycle range: 1 ~ 99% duty cycle Pulse signal amplitude: 5 VDC, maximum amplitude 5.0Vp (output amplitude unchanged) Servo signal frequency: 100 Hz Servo signal pulse width: 500 ~ 2500 us Voltage: 7 ~ 12 VDC Working current: <50 mA Working temperature: -40 °C ~ 65 °C Storage temperature: -40 °C ~ 65 °C Size: 57mm * 45mm * 20 mm Interface display and operating instructions: P4 connector (power supply) VDD: power supply positive(7 ~ 12V) GND: power supply negative P3 interface (output signal) Q1: Not used to. Q2: not used to. CP: pulse signal output. GND: power supply negative. Key Description FUN: Select the setup data bits. UP: Previous. DOWN: Next. LEFT: Self plus key. ROGHT: decrement key. Set frequency plot: Set the Duty Cycle diagram: Servo signal pattern diagram: Frequency Counter: Oscilloscope waveforms Two positive and negative pulse signal output 1kHz Servo signal 500us: Payment Policy: We ONLY accepted PayPal payment. We will ship to the shown address on you PAYPAL Payment notice, Please confirm your shipping address in the PayPal Account. If you don't have Paypal account, please sign up and learn more about paypal at: www.paypal.com. Payment must be fulfilled within 7 days since auction's ending. shipping & time: Generally, delivery time is 10-20 business days to USA, United Kingdom, Australia and 15-30 days to most other countries. Items will be shipped within 1 business day on payment received. Delivery time depends on destination and other factors, it may takes up to 30 business days. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Returns Policy: All sales come with us 14-day warranty. Return items must not be used or have any sign of abuse or intentional damage. Buyer is responsible for all return shipping charges. We reserve the right not to refund S&H when the item has been posted. Contact us: If you have any questions,Please contact with us via eBay message or our customer service e-mail. please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 11:00 - 20:00 and Saturdays 11:00 - 15:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) Feedback: Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us a positive feedback . When you rate the shipping time part please take international transit into consideration. Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and pleasant shopping with us. Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. thank you !
