New Qualiflow Afc 202 H2 100 Slm Mass Flow Controller Mfc Asm Pn: 54-123324a73

US $540

Phoenix, Arizona, United States
Jun 14th

Open on mobile:
QR code

NEW Qualiflow AFC 202 H2 100 slm Mass Flow Controller MFC ASM PN: 54-123324A73 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Advanced Energy and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This part is new, old stock from ASM. The package may have been opened and re-sealed to recalibrate the units so that ASM could ship them when a customer ordered them. The calibration is past due however. ASM Information: Part Number: 54-123324A73 Description: FC-QFLW 202-H2-100 SLM-VID-NO @ 30 The Unit's Tag Reads: Model Number: AFC-202 Part Number: 202OVEE100L007D Flow Range: 100 slm Gas: H2 Description: AFC 202 NO VT 100L H2 3/8 VCR MM VID Link to the Datasheet: Qualiflow AFC-202 & AFM-302 Series Mass Flow Controller & Meter Datasheet Link to the Manual: Qualiflow AFC-202 Mass Flow Controller Manual Features: Unique fast and reliable horizontal magnetic valve. Normally open and normally closed version available with colour identification (green for NO, red for NC). Special pressure compensated stainless steel valve for ultra fast flow control. No particle generation or entrapment. Specifications: Flow Range (equivalent N2): 30 sccm to 250 slm, up to 400 slm with H2 (this unit is setup for 100 slm) Control Range: 2 - 100% F.S. Valve Type: Electromagnetic Valve Rest Position: Normally Open or Closed Accuracy: ±1% of F.S. Linearity: ±0.5% of F.S. Repeatability: ±0.3% of F.S. Sensibility to Mounting Position: ±0.1% of F.S. Step Response Time: ~5 sec. typical (SEMI E17-91) Operating Temperature: 5 ~ 40°C, non-condensing Temperature Coefficient: < 0.5% F.S./°C Maximum Inlet Pressure: 1 MPa (10 bar, 150 psi) Minimum Differential Pressure: 250 kPa for 100 slm F.S. Pressure Coefficient: < 0.1% F.S./105 Pa Wetted Materials: 316 L Stainless steel Surface Finish: 0.4 µm (16 µinch) Ra max Leak Integrity: < 2.10-9 atm.scc/sec (He) Standard Seals: Viton, Neoprene Fittings: 3/8" M VCR, Swagelok Weight: 3.7 Kg Input and Output Specifications: Mass Flow Meter: ±15 VDC, 50 mA Input and Output Signal: From 0 to 5 VDC Electrical Connector: Card edge For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $5.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 03/05/12 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
