New Rigol Dsa1000-amk Spectrum Analyzer Us Authorized Dealer

US $2000

Jonestown, Pennsylvania, United States
Jun 9th

Open on mobile:
QR code

Sign up for our newsletter Rigol DSA1000-AMK Spectrum Analyzer Measurement Package Option Part Number: RIGOLDSA1000-AMK Manufacturer's Description Spectrum Analyzer Measurement Package Option Need Help With Your Purchase? We would love to help. Speak with an agent today! These are factory NEW units. We are an Authorized USA distributor. With us, you will get USA based support and a USA based warranty. Beware of buying from overseas dealers. They will not give you a USA based warranty. All ebay orders ship via UPS within 24 hours of ordering with full tracking ability. Description Rigol DSA1000-AMK Spectrum Analyzer Measurement Package Option Advanced Measurement Kit Functions Option DSA1000-AMK provides plenty of advanced measurement functions including T-Power (Time domain Power), ACP (Adjacent Channel Power), Chan Pwr (Channel Power), OBW (Occupied Bandwidth), EBW (Emission Bandwidth), C/N Ratio, Harmo Dist (Harmonic Distortion), TOI (Third Order Intermodulation) and Pass/Fail. The measure mode can be Single or Continuous and you can control the measurement status: Restart, Pause or Resume. Pressing the front panel key Meas, the corresponding menu will appear on the right of the screen. Press Meas Fctn and choose a measurement function. The screen will be divided into two windows. The upper one is for basic measure, displaying sweep trace, and the lower one shows the measurement results. T-Power (Time domain Power) Enables the Zero Span Mode and calculates the power within time domain. The measurable power types are Peak, Average and RMS. ACP (Adjacent Channel Power) Measures the power of the main channel and the adjacent channels and calculates the power difference between the main and each of the adjacent channels. When enabled, both the span and resolution bandwidth of the analyzer are adjusted to be smaller automatically. Chan Pwr (Channel Power) Measures the power and the power density within a specified channel bandwidth. The span and bandwidth are automatically set to smaller values in this measurement type. OBW (Occupied Bandwidth) Calculates the power within whole bandwidth by integral operation and works out the occupied bandwidth by this value based on the specified power ratio. The center frequency difference between the measured channel and the analyzer will also be given in the measurement results. EBW (Emission Bandwidth) Measures the bandwidth of the two points at both sides of the max signal when the amplitude of this max signal falls off X dB within the span range. C/N Ratio Measures the power of both the carrier and the noise within specified bandwidth and calculates their ratio. Harmo Dist (Harmonic Distortion) Measures each order harmonic power and THD (Total Harmonic Distortion) of carrier. The available range is up to 10 orders. And the fundamental wave amplitude of the carrier must be higher than -50 dBm or else the measurement will be invalid. TOI (Third Order Intermodulation) Measures the parameters of the TOI production generated by two signals which have the same amplitude and similar frequency. The measured results include the frequency and amplitude of the Base Lower, Base Upper, 3rd Order Lower and 3rd Order Upper signals, as well as the Intercept of both the 3rd Order Lower and 3rd Order Upper signals. Pass/Fail Compares the measured curve with the pre-edited, if the related rules are met, the result will be “Pass”, or else is “Fail”. Advanced Measurement Functions We offer the full manufacturer warranty on most products. Please contact us if you have any questions! About Tequipment.NET Tequipment.NET is one of three divisions of InterWorld Highway, LLC, a well established, authorized manufacturer / distributor of major brands of test equipment. TEquipment.NET provides electrical testing equipment and products for a wide range of electrical applications. We offer an exceptional price match guarantee on qualifying electrical test and measurement tools. In addition, qualifying electric test product orders are shipped free!
