New Stamford Generator Avr As440 Auto Voltage Regulator

US $2500

Shenzhen, China
Jan 30th

Open on mobile:
QR code

New Stamford Generator AVR AS440 Auto Voltage Regulator AS440 General description AS440 is a half wave phase controlled thyristor type AVR and forms part of the excitation system for a brushless generator. The design employs Surface Mount Technology (SMT) for high integration of features in a small footprint AVR. Positive voltage build up from residual levels is ensured by the use of efficient semiconductors in the power circuitry of the AVR. The power and voltage sensing circuits have separate terminals, allowing the excitation power to be derived directly from the stator winding for basic applications or from an auxiliary winding if sustained short circuit performance is required. The AVR is linked with the main stator windings and the exciter field windings to provide closed loop control of the output voltage with load regulation of +/- 1.0%. The AVR voltage sensing terminals continuously sample the output windings for voltage control purposes. In response to this sample voltage, the AVR controls the power fed to the exciter field, and hence the main field, to maintain the machine output voltage within the specified limits, compensating for load, speed, temperature and power factor, of the generator. Over excitation conditions are limited to a safe period by a protection circuit within the AVR. Provision is made for the connection of a remote voltage trimmer, allowing the user fine control of the generator's output. An analogue input is provided allowing connection to a Newage Power Factor controller or other external devices with compatible output. The AVR has the facility for droop CT connection, to allow parallel running with other similarly equipped generators. Technical specification SENSING INPUT Voltage Jumper selectable 100-130 Vac 1 phase or 190-264 Vac 1 phase Frequency 50-60 Hz nominal POWER INPUT Voltage 100-264 V ac 1 phase Frequency 50-60 Hz nominal OUTPUT Voltage 82 V d. C. @ 200 V a. C. Current continuous 4A (see note 1). Transient 7.5A for 10 secs. Resistance 15 ohms min (10 ohms min when input volts is less than 175 ac) REGULATION +/- 1.0% (see note 2) THERMAL DRIFT 0.03% per deg. C change in AVR ambient (see note 3) TYPICAL SYSTEM RESPONSE AVR response: 20 ms Filed current to 90%: 80 ms Machine Volts to 97%: 300 ms EXTERNAL VOLTAGE ADJUSTMENT +/-10% with 1 k ohm 1 watt trimmer (see note 4) Increasing resistance lowers voltage. UNDER FREQUENCY PROTECTION Set point: 94 -98% Hz (see note 5) UNIT POWER DISSIPATION 12 watts maximum BUILD UP VOLTAGE 4 Volts @ AVR terminals ANALOGUE INPUT Maximum input: +/- 5 Vdc (see note 6) Sensitivity: 1V for 5% Generator Volts (adjustable) Input resistance 1k ohm QUADRATURE DROOP INPUT 10 ohms burden Max. Sensitivity: 0.07 A for 5% droop 0PF Max. Input: 0.33 A OVER EXCITATION PROTECTION Set point 75 V dc Time delay 10-15 seconds (fixed) ENVIRONMENTAL Vibration: 20-100 Hz 50mm/sec 100Hz -2kHz 3.3g Operating temperature: -40 to +70? C (note 7) Relative Humidity: 0-70? C 95% (note 8) Storage temperature: -55 to +80? C Edited by Miriya PAYMENT INFORMATION: 1.We can accept Credit Cards,Paypal,T/T,Escrow and so on. 2.The buyer is responsible for any tax and/or duty charged by their country. INTERNATIONAL SHIPPING: The package will be shipped by China Post or Epacket . After we shipped the parcel,we'll fill in the tracking number and inform you by e-mail.Please write the correct address and telephone number when you make orders,so the courier can contact you when they deliver the parcel to you. thanks WARRANTY INFORMATION: 1.All the products have been checked and packed in good condition before dispatch. 2.All the products with one year warranty. 3.If you find any quality problems,please send it back within 3 days,and we'll send you a new one or refund you the payment after we get the returned one. 4.Buyers have to pay for the return cost and we will pay the cost for resend 5.All products returned should be in new conditions. CONTACT US: Office Tel: 008675527541660 Cellphone: 008615967476828 1.A good feedback is very important for our store,if you feel satisfied with our products,please give us positive feedbacks. 2.Please contact us before leaving any negative or neutral feedback,We will work with you to solve any problems.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	OEM
Model	AS440
