New Top Dc-dc Adjustable Step-up Power Converter Module Xl6009 Replace Lm2577

US $1.43

CN, China
Mar 11th

Open on mobile:
QR code

New TOP DC-DC Adjustable Step-up Power Converter Module XL6009 Replace LM2577 Description IN-IN + input Positive Input Negative! Positive output OUT + OUT-output negative Test comparison sample reference: Input 3V Output 12V 0.4A 4.8W Input 5V Output 12V 0.8A 9.6W Input 7.4V Output 12V 1.5A 18W Input 12V Output 15V 2A 30W Input 12V Output 16V 2A 32W Input 12V Output 18V 1.6A 28.8W Input 12V Output 19V 1.5A 28.5W Input 12V Output 24V 1 A 24W Vin * Iin * Efficiency = Vout * Iout Vin: Input Voltage Iin: input current Vout: Output Voltage Iout: output current DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated. ● Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V; ● Wide Output voltage 5V ~ 35V; ● Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A) ● high switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Description: 1.Module properties: the isolation booster module. 2.The input voltage: 5-32 V. 3.Output voltage: continuous adjustable (5.5-35 V). 4.Output current: 3 A (MAX). 5.The input current: 4 A (MAX). 6.Input methods: IN+ input is level, IN- input negative. 7.Output way: OUT+ output is level, OUT- output negative. 8.Adjust way: first correct by input power supply (5-32 V, between) again using a multimeter to monitoring output voltage and the potentiometer (turn step-down, in reverse chronological turn boost). 9.Output voltage: 5-35 V continuous adjustable (the construction no-load commissioning). 10.Size: 43mm x 21mm x 14mm. Payment We accept payment via PAYPAL ONLY. Payment must be made within 4 days of auction closing. S&H will be determined based upon the SHIP TO address. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. Please list your special requests (size ,color, packages, value of declaration, etc.) in the PAYPAL NOTES SECTION when you make payment. Shipping Orders processed within 24-48 hours of payment verification. We only ship to confirmed PAYPAL addresses. Your PAYPAL address MUST MATCH your Shipping address. The images shown are not the actual item and are for your reference only. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary, particularly during the holiday season. If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! Delivery Time: China Post International Air Mail Delivery Time Info: Destination Working Days 5-7 8-11 12-14 15-19 20-22 >22 Working Days+Saturday+Sunday 5-9 10-15 16-20 21-25 26-30 >31 USA Rate(item arrived) 4.9% 50.1% 29.6% 10.5% 4.7% 0.2% Canada Rate(item arrived) 0.0% 46.2% 31.4% 17.6% 3.9% 0.9% U.K Rate(item arrived) 9.7% 28.6% 43.8% 10.1% 7.0% 0.8% Australia Rate(item arrived) 21.1% 50.0% 14.3% 7.2% 7.1% 0.3% Europe Rate(item arrived) 8.9% 22.2% 30.3% 20.9% 15.5% 2.2% Italy Rate(item arrived) 0.0% 10.3% 19.6% 18.3% 31.3% 20.5% About Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback,or open any dispute on PayPal. so that we can satisfactorily address your concerns. It is impossible to address issues if we do not know about them! IF you have any question please contact us, We can reply you within 8 hours. Contact us If you have any questions,Please use Ebay Message to contact us.(Saturday and Sunday are not working). Return Policy You have 7 days to contact us and 10 days to return it from the date it was received. If this item is in your possession more than 7 days, it is considered used and WE WILL NOT ISSUE YOU A REFUND OR REPLACEMENT. There are NO EXCEPTIONS! All returned items MUST BE in the original packaging and you MUST PROVIDE us ,specific reason for the return, and your eBay ID. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from eBay. OR, you may choose to have a replacement Return shipping is to be paid by the Buyer. Engineered for professional eBay sellers! On Mar-11-15 at 12:12:47 PDT, seller added the following information:
