Newport Mfn25pp Minature Linear Translation Stage Esp Compatable 25mm Travel

US $399.00

Minneapolis, Minnesota, United States
Apr 25th

Open on mobile:
QR code

This auction is for a Newport MFN25PP Linear Translation Stage. Your bid is for 1, but 2 are available. FREE SHIPPING in the USA! The Newport MFN25PP Miniature Linear Stage is now called the Newport MFA-PP. The MFN25PP has a range of 25mm and is ESP Compatible. The main body is made of Stainless Steel, and the slide runs on double-row ball bearings. Minimal incremental motion is 0.1 micron and the maximum speed is 2.5 mm/s. Designed for space-limited applications and compact multi-axis assemblies, MFN Series linear stages supply very high resolution, single-axis translation in a low-cost, motorized package. Typical applications for this stage are fiber optic alignment, laser diode research, and inspection systems. Components mount to the top surface of the stage via tapped mounting holes. Modular stage design facilitates easy assembly of MFN Series stages into multi-axis configurations. A miniature DC-or stepper motor, housed within the carriage of the stage, actuates motion via a backlash-compensated lead screw and nut system. Precision-ground, double-row ball bearings ensure accurate linear travel. To meet high positioning requirements, a motor-mounted rotary encoder delivers better than 0.1 ?m resolution. End-of-run limit switches prevent bearing damage from accidental over-travel. For optimal performance, we recommend the use of our ESP or MM series motion controllers. The (M-)MFN Series stages are supplied with a 3-meter cable for connection to our motion controllers. 2.1 Design Details Base Material Stainless Steel Bearings Double row linear ball bearings Drive Mechanism Backlash-compensated leadscrew Drive Screw Pitch 0.5 mm Reduction Gear 141:1 Feedback (M-)MFNPP: Motor mounted rotary encoder, 48 pts/rev. (M-)MFNCC: Motor mounted rotary encoder, 64 pts/rev. Limit Switches Mechanical Origin Uses motor side limit for homing, typically <20 ?m repeatability Motor (M-)MFNCC: DC-servo motor UE16CC (M-)MFNPP: 2-phase stepper motor UE16PP, 1 Full step = 2 Encoder pulses Cable Length 1.5 m Vacuum Compatibility Vacuum compatible versions are available up to 10-6 Torr: (M-)MFN08PPV6 and (M-)MFN25PPV6 3.2 Mechanical Specifications Travel Range (mm) 8; 25 Resolution (?m) 0.055 (DC-Brush Servo), 0.074 (Stepper motor) Minimum Incremental Motion (?m) 0.2 Unidirectional Repeatability (?m) 1 Reversal Value (Hysteresis) (?m) 3 On Axis Accuracy (?m) 10 Maximum Speed (mm/sec) 0.3 Roll (?rad) 60 Pitch (?rad) 100 Yaw (?rad) 100 3.3 Load
