NewScope-T1 LCD display kit for Tektronix TDS 724A 724C 724D 714L Oscilloscopes, US $1554 – Picture 0
NewScope-T1 LCD display kit for Tektronix TDS 724A 724C 724D 714L Oscilloscopes, US $1554 – Picture 0

Newscope-t1 Lcd Display Kit For Tektronix Tds 724a 724c 724d 714l Oscilloscopes

US $1554

  • Santa Clara, California, United States
  • Jun 6th
Open on mobile:
QR code
The NewScope-T1 Color LCD replacement Kit is designed to replace the Color CRT displays used in Tektronix TDS 600 and 700 series digital oscilloscopes and the TLS216. It replaces the display subsystem including the CRT and the CRT driver board. The Kit supports 6.5 inch TFT color LCD at VGA (640 x 480) resolution.  The supported oscilloscope models include: TDS 644A 644B 654C TDS 684A 684B 684C 694C TDS 724A 724C 724D 714L TDS 744A 754C 754D TDS 784A 784C 784D 794D The Key features include: Digitally reproduces all original colors designed for the CRT Supports individual intensity adjustment of the display elements Supports InstaVu and DPO acquisition waveform display Symmetric mounting bracket to optimize for different viewing directions Easy installation, no soldering required (major components shown in the pictures) Does not use signals from the rear VGA output port, retains the VGA output feature, and is free from video background noise in A-to-D conversion solutions. Includes a high-brightness, 6.5" Industrial LCD panel with long-life LED back light Please download the operating manual with installation instructions following the link: http://simmconnlabscom.ipage.com/tech/NewScope-T1_OM.pdf
