Ni Pxi-4495 , National Instruments 24-bit, 204.8 Ks/s, 16 Inputs,adc Dac Dsa Daq

US $1,999.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PXI-449524-Bit, 204.8 kS/s, 16 Inputs New, unused item, only PXI card in original packaging 16 simultaneously sampled analog inputs at up to 204.8 kS/s 24-bit resolution ADCs with 113 dB dynamic range 2 gain settings up to +20 dB Software-selectable analog input ranges of ±1 or ±10 V Variable antialiasing filters DC-coupled analog inputs Manufacturing price: $8500 More information The National Instruments PXI-4495 is a high-accuracy data acquisition module specifically designed for high-channel-count sound and vibration applications. With 16 simultaneous channels in a single PXI module, it has twice the density of any other simultaneously sampled device from NI. When you use the NI PXI-4495 in an 18-slot PXI chassis, you can synchronize up to 272 channels. And because the module is programmed with NI-DAQmx featuring DAQmx Channel Expansion functionality, data acquisition code is the same for one channel, 16 channels, or 272 channels. For even larger noise mapping microphone arrays, dynamic structural test, or data streaming applications, you can synchronize more than 13,000 channels in a multichassis PXI system. The PXI-4495 module features a maximum sampling rate of 204.8 kS/s per channel General Product Name PXI-4495 Product Family Dynamic Signal Analyzers Form Factor PXI Platform PXI Bus Type PXI Hybrid Compatible Part Number 780059-01 Operating System/Target Real-Time , Linux , Windows LabVIEW RT Support Yes Power Requirement for +3.3V Rail 1.7 A Power Requirement for +5V Rail 0.8 A Power Requirement for +12V Rail 0.4 A Power Requirement for -12V Rail 0.1 A Slot Two Module No Module Width 1 MXI Compatible Yes DAQ Product Family SC Series Measurement Type Voltage RoHS Compliant Yes Signal Conditioning Anti-aliasing filter Analog Input Channels 0 , 16 Single-Ended Channels 16 Differential Channels 0 Resolution 24 bits Sample Rate 204.8 kS/s Max Voltage 10 V Maximum Voltage Range -10 V - 10 V Number of Ranges 2 Simultaneous Sampling Yes On-Board Memory 4095 samples Total Harmonic Distortion (THD) 98 dB Dynamic Range 114 dB Excitation Current 4 mA Analog Output Channels 0 Digital I/O Bidirectional Channels 0 Input-Only Channels 0 Output-Only Channels 0 Counter/Timers Counters 0 Physical Specifications Length 16 cm Width 10 cm I/O Connector InfiniBand connector Timing/Triggering/Synchronization Triggering Digital , Analog

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PXI-4495
