NoiseKen EMI Noise Meter FVC-1000 with 2 Probes and 20dB Attenuator, US $760 – Picture 0
NoiseKen EMI Noise Meter FVC-1000 with 2 Probes and 20dB Attenuator, US $760 – Picture 0

Noiseken Emi Noise Meter Fvc-1000 With 2 Probes And 20db Attenuator

US $760

  • Canton, China
  • Jun 22nd
Open on mobile:
QR code
  NoiseKen EMI Noise Meter FVC-1000 with 2 Probes and 20dB Attenuator Product Description This is the NoiseKen EMI Noise Meter. It comes complete with 2 probes and a 20dB Attenuator: Electric Near Field F-10-001. Magnetic Near Field F-10-002. 20dB Attenuator F-10-003. SPECIFICATIONS: Frequency Range: 30 MHz to 1000 MHz in four LED Display Bands. Adjustable Volume Level.   Noise Ken FVC-1000 EMI  Sensor in Original Case. Manufacturer: Noise Laboratory Co., LTD / Noise Ken Model No: FVC-1000 Electro-Magnetic Interference Measuring Instrument Frequency range:   Simultaneous 4 spectra measurement 30MHz to 88MHz. 88MHz to 216 MHz. 216MHz to 470 MHz. 470 MHz to 1000MHz.   Input snesitivity: Main unit input sensitivity: 0.224 - 7.07mV (-60 to -30dBm) 50 ohm system, 0.2236V = 0dB Electric field probe: 10-316mV Magnetic field probe: 0.06 - 2.0mA Level Display: For each frequency band: 20-point LED bargraph (1.5dB / point) Pulse response: 1uS min Dynamic range: 30dB     FVC-1000 main unit including : Electric field probe F-10-001, Magnetic field probe F-10-002 , Attenuator (20dB) F-10-003 Instruction manual and examples of protective measures to reduce radiated noise using the FVC-1000 Original Carrying case Main unit input sensitivity: 0.224 - 7.07mV (-60 to -30dBm) 50 ohm system, 0.2236V = 0dB Electric field probe: 10-316mV Magnetic field probe: 0.06 - 2.0mA Pulse response: 1uS min Dynamic range: 30dB Frequency range: Simultaneous 4 spectra measurement 30MHz to 88MHz 88MHz to 216 MHz 216MHz to 470 MHz 470 MHz to 1000MHz   It is in Voltage setting to AC230V, and it may be Changed the Voltage setting to AC115V . But it should be done by a Technicain becaust it needs to open the unit to do the setting!
