Non Asbestos Compressed Gasket Sheet 1/8 Thk X 12"x12"

US $590

  • Fort Lauderdale, Florida, United States
  • May 26th
NON ASBESTOS COMPRESSED SHEET  1/8 THK X 12" X 12" NA600  compressed non-asbestos gasket material. Application:  Suitable for oil resistant gasket material for light to medium loading.  Suitable for low operating pressure, e.g. transformers, compressors, and apparatus.   Also, used for easily deformable components with low surface pressure like valve covers and pans in internal combustion engines Suitable  gasket  material  for  medium  to  higher  load factors, with good resistance to water, gases, oils, fuels and  light  chemicals.   Used in compressors, pipelines, pumps,     transmission,    gas    meters     and     internal combustion engines. NON ASBESTOS COMPRESSED SHEET • Synthetic Fiber • Nitrile Binder • Excellent Sealability • Excellent Chemical Resistance • Good Creep Relaxation • General Purpose Sheet   THICKNESS: 1/8 WIDTH: 12" LENGTH:  12" COLOR: GREEN Continuous Max. Temp. (F)450 Degrees Temp. Range: (F)0 to 400 Degrees Max Peak Temp:  750F MAX PSI: 600 @ 100 Degrees F Liquid Tensile Strength: 1400 PSI   ITEM IS SOLD BY THE SHEET ONLY NOTE: All information and recommendations given in this brochure are correct to the best of our  knowledge. The information provided above should only be used as a guideline. Users must satisfy themselves that products are suitable for the intended process and uses.  Maximum temperature and pressure depends not only on the type of material but on the application conditions such as thickness, service, flange type and surface stress etc. FREE SHIPPING..
