Northwest Instruments Ntdm502 Total Station W/ Optical Plummet, Surveyor

US $3900

Kennesaw, Georgia, United States
May 31st

Open on mobile:
QR code

NTDM502 Total Station is built with dual axis compensation, ensuring accurate measurement. Advanced EDM shoots distance with 2mm+2ppm@D accuracy. On-board intelligence includes MLM, Stakeout, REM, Area calculation and more. RS-232C data port works with data collectors and PC, which makes data transfer quick and easy. Laser Plummet (NTDM502L) ensures convenient setups. Whether your job requires taking angles or distance, or conducting stakeout and complicated layout functions, NTDM502 is your solid tool to achieve higher efficiency. Item Includes: 5" Total Station with Optical Plummet RS-232C Data port Rechargeable battery pack (x2) Wall Charger w/ 220v adapter Tool kit Hard Carrying Case User Manual Telescope Image: Erect Objective aperture (EDM): 45mm Magnification: 30u00d7 Field of view: 1u00b020' Resolving power: 3.5" Mini focus distance: 1.1m Angle measurement Detecting system: photoelectric incremental encoder Angle unit: degree/gon/mil, selectable Minimum display: 1"/5"/10", selectable Detecting mode: Horizontal dual, Vertical angle single Accuracy: 5" Distance measurement Distance unit: m/ft, selectable Working range: Single prism: 6000ft Mini-reading: Fine mode 0.01ft, Tracking mode0.1ft Accuracy: +/-(2mm + 2ppm D) Measurement time: Fine mode: 2 sec; Tracking mode: 1sec Temperature unit: u00baC/u00baF, selectable Pressure unit: hPa/mmHg/inchHg, selectable Temperature input range: -30u00baC to +60u00baC (1u00baC steps) Pressure input range: 510hPa to 1066hPa(1hPa steps) Prism constant condition: -99.9mm ~ +99.9mm Refraction & earth curvature correction: OFF/0.14/0.2, selectable Prism constant correction: -99.9mm to +99.9mm Level vial sensitivity Plate level 30"/2mm Circular level 8'/2mm Compensation System: Liquid dual axis Range: +/-3' Resolving power: 1" Optical plummet (NTDM502) Accuracy: +/- 0.8mm/1.5m Image: Erect Magnification: 3u00d7 Focusing range: 0.5m - infinity Field of view 4u00b0 Display LCD: 8 linesu00d724 characters Illumination: Yes Internal memory: 16000 points Data Port: I/O RS-232C Power: Battery Ni-MH Rechargeable battery Voltage: 7.2V DC Operating Time: ~8 Hrs Distance & Angle; ~20 hrs Angle only Chargers: 100V to 240V 50/60Hz Charging time: (at +20u00b0C) Approx. 4 hours Working temperature: -20u00b0C - +50u00b0C Dimensions: 220u00d7184u00d7360uff4duff4d(Wu00d7Du00d7H) Weight: 14 lb. Waterproof: IP54 (IEC60529) RS-232C Data Port, works with data collectors, 6000 ft/single prism Dual Axis compensated, 2mm +/2 2ppm @ distance EDM accuracy. Thank you for giving me the opportunity to earn your business. MESSAGE ME FOR QUANTITY DISCOUNTS! RETURN POLICY If you are unhappy with this product for any reason, return the within 14 days delivery for a full refund. Just pay return shipping.
