Octo Relay Module

US $75.00

Amarillo, Texas, United States
Jan 30th

Open on mobile:
QR code

The D8129 is suitable for applications requiring Form "C" relay to operate auxiliary systems or to display fire system status at remote annunciators. Building components such as HVAC, door lock releases, and stairwell pressurization can be interfaced with the D8129 for complete system control and monitoring. Industrial, commercial, and institutional facilities are typical installations for the D8129 module. The eight on-board relays can be programmed to activate on system alarm, system trouble, individual zone or point faults, and through remote control by authorized users. System Overview The D8129 Octo-Relay module provides eight programmable Form "C" relays. Each relay provides dry contact switching rated for 1.0 amp at 12 VDC. The relays are accessed through on board screw terminal connections. The Octo-Relay Module uses information from the control/ communicator serial data output to activate the relays. On-board switches are used to configure the Octo-Relay Module for different operating modes, or to specify relay output numbers. These switches, along with panel programming options, determine the D8129’s response to the serial data. Programming within the panel can activate specific relays or set of relays in response to system conditions. For the 9000 Series, slide switches are configured for specific relay output numbers, which are activated according to their programming. The D8129 Octo- Relay Module uses five slide switches with multiple setting options to configure its mode of operation. The D8129 receives serial data from the control/communicator and activates relays in response to panel conditions and slide switch settings. Relays can be programmed for remote control from a panel command center. Basic Functions Output relays Each relay output provides a normally open and a normally closed output. Modes of operation A slide switch with multiple switch settings can be used to configure the module for a specific mode of operation for D8112 Series systems, or programming can be used to determine relay operation for 9000 Series systems. Planning Up to four D8129 Octo-Relay Modules can be mounted in a control/communicator enclosure. For additional modules, use the D137 Mounting Bracket. The D8129 connects to a panel using the 12 VDC Auxiliary output, Serial Data Output, and common terminals. D8129 Octo-Relay Module Prod. ID D8129 • Programmable relay functions • Provides 8 Form "C" relays • 1 amp at 12 VDC relay contact rating • Operates with the D8112 (serial bus) and 9000 Series (Zonex bus) communicator panels • Slide switch configuration • Allows remote control of relays • Screw terminal connections ALL SALES ARE FINAL. TEXAS, OKLAHOMA, AND NEW MEXICO MUST PAY SALES TAX!!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Octo-relay Module
Model	D8129
