Olympus Micro 4/3 0.5x Relay Lens Adapter To Microscope Lumix Dmc-gf123 Gh1 G1

US $69.55

Shirley, New York, United States
Jan 30th

Open on mobile:
QR code

10/2014, 80 4 + 31 You are bidding on a Microscope Camera Adapter Kit for a Olympus Micro Four Thirds bayonet. This lens is a 0.5x which gives you my widest field of view. The following digital cameras use the Micro Four Thirds concept Olympus PEN, E-P1, E-P2, E-P3 Panasonic Lumix DMC-GF1,-GF2,-GF3, GH1, G1 and more.....I, and more. If your not sure about your specific model Email me and I'll let you know This is exactly picture of what you are buying . The Olympus M4/3 bayonet adapter (left side) and 0.5x male relay lens (right side) The next picture below are adapter sleeves which are also included with this sale. This relay lens gives you my widest field of view (FOV) than my 1x lens. The additional microscope adapter sleeves slide on the male relay lens end to give you a total of three sizes 23.2 (no adapter used) ,30, and 30.5 mm for insertion into a standard camera port, or trinocular, microscope or macroscope eyepiece. See example pictures below. The actual 0.5x relay lens mounted on a Olympus Pen PL-1 This is an example of a 1x relay lens being unscrewed from the bayonet mount. You are actually purchasing a 0.5x relay lens as shown above. Why a 0.5x? This unit gives you a wider field of view. The relay lens has a standard one inch (25.4 mm) diameter, with 32 threads per inch designated as "1-32 UN 2A". This is the thread that most digital cameras use for scientific applications. Sliding on one of the sleeves allows you to change from the standard Trinocular camera port to a Microscope or Macroscope eyepiece insertion when a camera port is not an option . (picture is actually of a 1x relay lens) Microscope eyepiece removed and sleeve with 1x relay lens being inserted . Please keep in mind that I sell this design for many different camera makes and models so the picture may be another camera. or relay lens. Actual canon camera mounted into eyepiece using the adapter with a 0.4x relay lens. A standard inch diameter camera port being used to attach to the 0.4x relay relay lens, bayonet and camera . This is a picture of a Olympus Pen Camera with the front lens removed to show the "Micro Four Thirds mount" which is a three lug bayonet style connector To view my other current auctions now click here. Micro 4/3 Four Thirds list - Olympus PEN, E-P1, E-P2, Panasonic Lumix DMC-GF1,-GF2,-GF3, GH1, G1 and more.... Olympus PEN Micro 4/3 0.4x relay lens ADAPTER to Microscope PL1-PL2 Panasonic Lumix Olympus PEN Micro 4/3 0.4x relay lens ADAPTER to Microscope PL1 PL2 EPL3 EPL123 Panasonic Micro 4/3 0.4x relay lens ADAPTER to Microscope lumix DMC-GF123 GH1 G1 micro 4/3 Four Thirds DSLR SLR CAMERAS F-mount C-Mount adapter Kit single lens reflex digital
