Operation & Test Data Manual For Hickok 534a Tube Tester

US $12.50

  • Orange Park, Florida, United States
  • Jan 29th
Open on mobile:
QR code
This is a very nice comb bound reprint of the operating manual for the Hickok 534A tube tester. The Hickok 534 is the same as the 532 with the addition of VOM circuitry and can measure Volts, resistance, milliamps, microfarads, and decibels. It is very similar to the 533 which was made from 1949 to 1952, but is actually the earlier model (1949) and does not have a socket for testing 9 pin Magnoval (gap between pin 1 & pin 9) miniature tubes. It does have a socket for the oddball Noval 9 pin tubes with no gap between pin 1 and pin 9. These three models use the same testing data, and the calibration instructions for the 533 are included in this book. A nice big fold-out schematic is included. Test data #3200-44 dated November 1961 is included, plus a later supplement. The stiff covers are protected with clear sheets. First class postage is free in the USA.  Payment via Paypal is expected within 3 days. Please check my store for lots of great manuals. Posted with the eBay Android app
