Otdr 1310/1550nm, 24/22db, Aor500s Fc,sc With1mw Visual Fault Locator

US $1,199.00

??, ???, China
Jun 9th

Open on mobile:
QR code

Description: This advanced diagnostic tool for optical fibres allows the Fibre Engineer to take a snapshot of a fibre link.The OTDR sends short pulses of light down one end of a fibre at a specified repetition rate.Light reflected back from fibre discontinuities and light continuously back scattered from the fibre itself travels back to the OTDR, where the instrument records the optical power and arrival time.The arrival time of the pulse from a given point in the fibre is related to its distance from the OTDR.With this information, the OTDR graphically displays returned power versus distance.OTDRs are well-equipped for troubleshooting problems because they allow you to visually locate reflective events like connections and fibre breaks and non-reflective events like splices and tight bends by studying the graphical trace. The power difference between two points on the trace is an estimate of optical loss. Features: Automatic one-button testing Easy to operate for beginners and experts Integrated PALM design,small and light,easy to carry Short dead zone(8m) High performance & easy to use OTDR High speed signal processing, short test time and fast analysis Internal memory can store up to 10000 waveforms High contrast color TFT LCD Improved waveform quality USB port connect to PC Input laser signal auto detection and self-protection function Built-in VFL User-friendly OTDR simulation software shows details of events SPECIFICATIONS Model AOR500-S AOR500-A AOR500-B AOR500-C AOR500-B-S3S5S6 Dynamic Range* 24dB / 22dB 28dB / 26dB 32dB / 30dB 36dB / 34dB 32dB / 30dB / 30dB Max.Distance** 80km 100km 120km 140km 120km Wavelength 1550/1310nm 1550/1310nm 1550/1310nm 1550/1310nm 1550/1310/1625nm Event Dead Zone ** 1.5m Attenuation Dead Zone 8.0m Pulse Width 10ns, 25ns, 50ns, 100ns, 250ns, 500ns, 1us, 2.5us,5us,10us Distance uncertainty ±(0.8m ± 0.001% * testing distance ± resolution) Loss Resolution 0.001dB Min.Distance Resolution 1m Connector FC FC, SC FC, SC FC, SC FC, SC VFL 1mW Data Storage > 10000 traces (standard 1GB SD card) Display 3.5 inch TFT color LCD Interface USB Battery Built-in rechargeable battery Working Time >10 hrs (Bellcore TR-NWT-001138) * pulse width 10us, average time>5 minutes, SNR=1, 23°C±2°C ** at 1550nm, one fiber without adapter and splicing connection inside ** pulse width 10ns, terminal refection loss>40dB GENERAL SPECIFICATIONS Size(H*W*D) 197mm * 107mm * 67mm Weight About 750g Storage Temperature -20°C -- +60°C , < 90%RH Operating Temperature -10°C -- +50°C , < 90%RH ACCESSORIES Standard OTDR Main unit*1 USB cable*1 AC/DC adapter with power cord*1 SD card*1 Operation guide*1 SC interchangeable connector*1 (optional for AOR500-S) Carrying bag*1 Certificate of Calibration*1

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Tribrer
MPN	Does Not Apply
Model	AOR500-S
Country/Region of Manufacture	China
