Outback STX RTK GLONASS, US $6,750.00 – Picture 0

Outback STX RTK GLONASS, US $6,750.00 – Picture 1

Outback STX RTK GLONASS, US $6,750.00 – Picture 2

Outback Stx Rtk Glonass

US $6,750.00

Neche, North Dakota, United States
Mar 28th

Open on mobile:
QR code

Outback STX, fully unlocked RTK, GLONASS, and Eturns!! Retails $8095.This unit is fully equipped, with all unlocks. Specifications Communication Serial Port: RS232, DB-9 Radio Interface via Serial Port: 2x CAN: 2x USB: 1x 2.0 Host Ethernet: 1x through cabling Ground Speed Interface: 4-pin circular Data I/O Protocol: NMEA 0183, NMEA 2000 Environmental Operating Temp: -20C to +60C (-4F to 140F) Storage Temp: -40C to +85C (-40F to 185F) Enclosure IP rating: IPx4 Vibration: EP455 Mechanical vibration – Random section 5.15.1 Shock: EP455 Mechanical shock – Operational section 5.14.1 EMC FCC part 15, Subpart B CISPR22:2008 ISO14982 Power Input Voltage: 9 - 36 VDC Power Consumption: 12W Current Consumption: 1.0 A @ 12 VDC Antenna A50 – GPS L1/L2/L5, GLONASS L1/L2, Beidou, SBAS, L-band DGNSS/HP/XP (OmniSTAR), Galileo E1/E5a and b Audio 1x single frequency buzzer Computer Processor: ARM Cortex-A8 @ 800MHz Storage: 8MB NOR, 2GB NAND, 512MB DDR3 RAM Operating System: Linux Display Type: 7” LCD TFT WVGA (800x480 res) Mechanical Case: Aluminum Weight: 1.14 kg (2.5 lbs) Mount: Adjustable 1” RAM Ball Mount Screen Size: 154.4mm x 91.44mm (6.0” x 3.6”) GNSS Receiver Receiver Type: GNSS L1 & L2 RTK with carrier phase Signals Received: GPS & GLONASS (with subscription) Channels: 270 Update Rate: 1 Hz standard, 10 Hz optional L-band: Optional LX-2 board • Integrated Eclipse™ P300™ GNSS receiver offering easy scalability from L1 GPS to L1/L2 GNSS • GLONASS unlocked • OmniSTAR option available* • RTK correctors through a combination of the Outback MAX rover and any one of Outback’s portable or fixed base stations such as A321, A221, and BaselineX • Compatible with Outback’s entire autosteer line including eDriveXC and eDriveXD • 7” high-resolution touch screen

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Outback
MPN	910-4012-000
Model	STX
