Paroscientific,inc. Digiquartz® Portable Pressure Standard Model 760 ( New )

US $2500

Moncks Corner, South Carolina, United States
Jun 23rd

Open on mobile:
QR code

THIS IS NEW -OLD STOCK Model 760 Portable Pressure Standard Paroscientific,Inc. Digiquartz® Pressure Instrumentation The Model 760 Portable Field Standards provide the highest accuracy pressure measurements for process, metrology and meteorology applications. Typical application accuracy of 0.01% of full scale or better is achieved as a traveling standard and in laboratory conditions. Desirable characteristics include 0.5” character, 6-digit LCD display, 1x10-8 resolution, no warm-up time, and high reliability. The standards are easy to interface with computer systems for remote data acquisition and instrument control. They are available with Digiquartz® Transducers in 19 absolute, 6 gauge and 3 differential pressure ranges. The Model 760 is portable, easy to use, and fully self-contained in a weather-proof rugged case. Turn it on and immediately read the pressure values in any of nine different user-selectable engineering units. All pressure readings are fully temperature compensated and linearized. Tare functions, pressure units, resolution, sampling rate, communication settings, baud rates, sensor address can be selected via the RS-232 interface. The unit is powered from an internal sealed battery for up to 200 hours, or continuously from an on-board AC/DC battery charger. Software is included to read and log data via the RS-232 port. PERFORMANCE 0.0001% Resolution 0.01% Full Scale accuracy or better RANGES 19 Absolute Pressure Ranges 0-15 psia (0.1 MPa) to 0-40000 psia (276 MPa) 6 Gauge Pressure Ranges 0-15 psig (0.1 MPa) to 0-200 psig (1.38 MPa) 3 Differential Pressure Ranges 0-3 psid (0.02 MPa) to 0-18 psid (0.12 MPa) FEATURES Taring RS-232 Interface 200 hours battery operation Simple, user-friendly front panel Weather-proof rugged case Configuration and logging software QUALITY AND STANDARDS NIST traceable ISO 9001 quality system High stability and reliability APPLICATION AREAS Metrology Aerospace Meteorology Oceanography Process Control Energy Exploration Reference Barometers Laboratory Instrumentation Paroscientific is certified to the ISO 9001 International Quality Standard. Our quality system and commitment to excellence ensure customers of outstanding products and services. PERFORMANCE Accuracy ………………………….… Better than 0.01% of Full Scale.(1) (2) CHARACTERISTICS Weight ……………………………….. 7.5 lb (3.4 kg) Max Power Requirements ………...……..115 or 220 VAC (Up to 200 hours on internal rechargeable battery) ENVIRONMENTAL Overpressure ………………………... 1.2 times Full Scale except 1.1 times Full Scale for 30K & 40K 1.0 times Full Scale for 500A Operating Temperature Range ……. 0 °C to +40 °C (+32 °F to +104 °F) PERFORMANCE 0.0001% Resolution 0.01% Full Scale accuracy or better RANGES 19 Absolute Pressure Ranges 0-15 psia (0.1 MPa) to 0-40000 psia (276 MPa) 6 Gauge Pressure Ranges 0-15 psig (0.1 MPa) to 0-200 psig (1.38 MPa) 3 Differential Pressure Ranges 0-3 psid (0.02 MPa) to 0-18 psid (0.12 MPa) FEATURES Taring RS-232 Interface 200 hours battery operation Simple, user-friendly front panel Weather-proof rugged case Configuration and logging software QUALITY AND STANDARDS NIST traceable ISO 9001 quality system High stability and reliability APPLICATION AREAS Metrology Aerospace Meteorology Oceanography Process Control Energy Exploration Reference Barometers Laboratory Instrumentation THIS UNIT IS IN NEW , UNUSED CONDITION. I OPENED THE BOX F0R PICTURES AND LISTING INFORMATION
