PB Post Base,No PB44Z, Simpson Strong Tie, US $170 – Picture 0
PB Post Base,No PB44Z, Simpson Strong Tie, US $170 – Picture 0

Pb Post Base,no Pb44z, Simpson Strong Tie

US $170

  • Walled Lake, Michigan, United States
  • Jun 2nd
Open on mobile:
QR code
PB Post Base,No PB44Z,  Simpson Strong Tie Product Information  The PB base embeds in wet concrete after pour and is made to install flush with the concrete surface. This connector was designed to help resist upload forces. Holes are provided for installation with 16d commons. A 2 minimum side cover is required to obtain the full load. Post bases do not provide adequate resistance to prevent members from rotating about the base and therefore are not recommended for non top-supported installations (such as fences or carports). 12-gauge galvanized steel. Some sizes available with ZMAX coating. No. PB44: Size: 3-9/16 W x 3-1/4 L, Post Size: 4 x 4, Material: Galvanized Steel, Gauge: 12 ga, Type: PB Base, Finish: Galvanized, Install With: 16d Fasteners, Uplift: 1365 lb, Pkg Qty: 1 No. PB44Z: Size: 3-9/16 x 3-1/4, Post Size: 4 x 4, Material: Galvanized Steel, Gauge: 12 ga, Type: PB Base, Finish: Z-Max, Install With: 16d Fasteners, Uplift: 1365 lb, Carton Qty: 10 pc, Pkg Qty: 1 No. PB66Z: Size: 5-1/2 W x 5-1/4 L, Post Size: 6 x 6, Material: Galvanized Steel, Gauge: 12 ga, Type: PB Base, Finish: Z-Max, Install With: 1/2 bolts, Uplift: 1640 lb, Pkg Qty: 1 No. PB46: Size: 5-1/2 W x 3-1/4 L, Post Size: 4 x 6, Material: Galvanized Steel, Gauge: 12 ga, Type: PB Base, Finish: Galvanized, Install With: 16d Fasteners, Uplift: 1365 lb, Pkg Qty: 1 No. PB66: Size: 5-1/2 W x 5-1/4 L, Post Size: 6 x 6, Material: Galvanized Steel, Gauge: 12 ga, Type: PB Base, Finish: Galvanized, Install With: 16d Fasteners, Uplift: 1640 lb, Pkg Qty: 1 Shipping Notes & Policies We ship VERY fast, therefore we cannot guarantee cancellations or address changes Perishable items are guaranteed to be in date or we will refund/replace them for free! Please allow 24 hours to respond to inquiries Return Policy Please allow us to resolve any issues before leaving feedback. We can solve any problem to your satisfaction! Returns require a valid RMA. Please message us and we will e-mail them to you Return shipment for defective items is paid for by us! Returns must be in NEW & UNUSED condition with all parts accounted for, in original packaging We do not stock parts. All replacements/exchanges require sending back the entire item.
